Поз.
Артикул
Описание
5
FRONT FENDER LEFT, 100001
11
PANELLING , FROM CHASSIS:011 100001
19
LOCK INSTRUMENT PANEL TO COWL
19
LOCK , Replaced By: A1269941345
24
LOCK
25
WASHER
35
PAD 2 MM
36
LOCK
47
WASHER
48
PAD RIGHT
49
RUBBER BUFFER , Replaced By: A1269870139
49
RUBBER BUFFER
50
LOCK
52
WASHER
54
LOCK
60
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
61
GARNISH MOULDING LEFT
62
GARNISH MOULDING LEFT
62
SEAL , Replaced By: A1148800182
63
FASTENER BUTTON
64
FASTENER BUTTON
64
GROMMET , Replaced By: A0019882081
64
FASTENER BUTTON , Replaced By: A0089970381
64
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
70
PARTITION PANEL LEFT
71
SEAL 770 MM ORDER BY THE METER
86
REINFORCEMENT
88
SCREW BRACKET TO FENDER,K 104588
100
BRACKET LEFT, 100001
110
PLUG
110
PLUGTO 123 880 12 70
114
REAR BUMPER FACE BAR LEFT
115
REINFORCEMENT
116
BUMPER JOINT COVER
128
BRACKET
139
RAIL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A1148850121
139
RAIL3100 MM
999
SCREW , Replaced By: N910105006002
999
NUT , Replaced By: N913012006001
999
NUT , Replaced By: N913019006000
999
NUT CLAMP TO BRACKET
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
HEXAGON HEAD BOLT
999
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
NUT BATTERY CABLE
999
NUT
999
SCREW CLAMP TO EXHAUST PIPE
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW PIPE CLAMP
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PUMP TO BRACKET
999
WASHER BRACKET TO COVERING
999
WASHER , Replaced By: N009021010209
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
SCREW
999
SHEET METAL SCREW ELECTRIC CABLE TO FIRE WALL
999
SHEET METAL SCREW CONTROL UNIT TO CAB B 5.5X19
999
SHEET METAL SCREW OIL LINE MOUNTING
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW HOSE TO FIRE WALL
999
SHEET METAL SCREW BRACKET TO FIRE WALL 6.3X22
999
SHEET METAL SCREW6.3X16
999
SHEET METAL SCREW BRACKET TO WINDOW SILL
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
TOOTHED WASHER , 123.020 082784 123.023 100522 123.026 050534 123.120 116041 123.123 080963 123.126 045537 123.130 101733
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N304032008006
999
NUT BALL PIVOT TO LEVER
999
NUT TACHOGRAPH TO BRACKET
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017010002
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008016
999
SCREW COVER PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
WASHER BOOT TO CAB FLOOR
999
WASHER AS REQUIRED 1.0 MM, ON BUSES UP TO CHASSIS 053510,ON TRUCKS UP TO CHASSIS 209647,FROM CHASSIS SEE 766.3
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
WASHER BRACKET TO SUPPORT
999
WASHER , Replaced By: N000125004319
999
TAPPING SCREW COVER AND BRACKET TO CAB CORNER PILLAR
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
RADIATOR GRILLE SHELL , FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 005,017 044524 015 262194 105,107,108,117,119 082984 110 444284 114 012374 115 277300, Replaced By: A1158880615
999
SEAL , Replaced By: A1158870298
999
RAIL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A1148850121
999
BUMPER JOINT COVER , 100001
999
PARTITION PANEL RIGHT, FROM CHASSIS: 000,002,010 000270 015 000142 100,102,103,110,112 000682 115 000300 FROM CHASSIS 005,017,105,107,108,117,119 000001
999
PARTITION PANEL , Replaced By: A1158840635
999
PARTITION PANEL , Replaced By: A1158840535
999
PAD RIGHT
999
PAD , Replaced By: A0039895485
999
PAD , Replaced By: A1158810997
999
FRONT BUMPER FACE BAR RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
FRONT BUMPER FACE BAR LEFT, 100001
999
FRONT FENDER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 005,017 015652 015 222251, Replaced By: A1158801018
999
ENGINE HOOD , Replaced By: A1158801157, +001A1078800060, +002N914126006001
999
FRONT FENDER RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
SEAL REPAIR KIT
999
ENGINE HOOD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 005,017 015652 015 222251, Replaced By: A1158801057
999
BRACKET RIGHT
999
RADIATOR GRILLE SHELL , FROM CHASSIS: 005,017 044525 015 262195 105,107,108,117,119 082985 110 444285 114 012375 115 277301
999
REAR BUMPER FACE BAR RIGHT
999
ENGINE HOOD CATCH
999
REPAIR KIT , Replaced By: A1158800997
999
SEAL , Replaced By: A1148800282
999
GARNISH MOULDING RIGHT
999
LEVER RIGHT, 000,001,004,010 FROM CHASSIS 108183,100,101,104,110 FROM CHASSIS 180688
999
ENGINE HOOD CATCH , Replaced By: A1158870006
999
SUPPORT RIGHT
999
HOOK , Replaced By: A1085860088
999
SLEEVE , Replaced By: A1085860088
999
PIN , Replaced By: A1085860088
999
HOOK , Replaced By: A1085860088
999
SPRING , Replaced By: A1085860088
999
SLEEVE , Replaced By: A1085860088
999
MERCEDES STAR , Replaced By: A1085860088
999
REPAIR KIT , Replaced By: A1155860288
999
ADHESIVE TAPE , Replaced By: A0019875646
999
LOCK GRILLE TO RADIATOR GRILLE SHELL,TOP LATERAL
999
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
999
LOCK PANELLING TO FRONT FENDER,BOTTOM
999
SCREW FRONT FENDER TO FRONT PANEL PILLAR
999
ADHESIVE TAPE , Replaced By: A0019875646
