Поз.
Артикул
Описание
12
WATER PUMP WITH GASKETS, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
12
WATER PUMP , Replaced By: A3532003601
12
WATER PUMP , Replaced By: A3532003701
12
WATER PUMP WITH GASKETS,760549 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
16
SHAFT ,937666/89, Replaced By: A3662010205, +001N000625900208, +001N000625900209
16
SHAFT
24
THRUST RINGTO 000 201 66 19/72 19
32
BOOTTO 000 201 66 19,000 201 72 19
40
SEAL WITH THRUST RING AND BOOT
40
SEAL , Replaced By: A0002019919
40
SEAL , Replaced By: A0002015719
40
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
40
SEAL , Replaced By: A0002016719
40
SEAL , Replaced By: A0002019219
40
SEAL , Replaced By: A0012011719
40
SEAL , Replaced By: A0012011819
40
SEAL , Replaced By: A0012011919
40
SEAL , Replaced By: A0012011919
40
SEAL , Replaced By: A0012012619
44
SEAL RING
44
SEAL RING
48
GROOVED BALL BEARING INTERMEDIATE BEARING
56
GROOVED BALL BEARINGTO 001 466 15 01
64
GASKET INCLUDED IN GASKET KIT,002823
64
GASKET , Replaced By: A3522012180
72
SEAL RING WATER PUMP
80
GASKET ,000118
80
GASKET
88
SEAL HOLDER
88
SEAL HOLDER
96
SEAL RING
96
SEAL RING
104
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
112
SCREW PLUG STABILIZER
120
HUB
128
GASKET WATER PUMP TO CYLINDER CRANKCASE
128
GASKET , Replaced By: A3642010280
134
COVER
142
LOCK PLATE , Replaced By: A0000710473
142
LOCK
150
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
158
IMPELLER PARTS KIT,740567
158
IMPELLER PARTS KIT,740566
158
IMPELLER , Replaced By: A3522003104
158
IMPELLER , Replaced By: A3522003304
158
IMPELLER , Replaced By: A3522003504
158
IMPELLER , Replaced By: A3522004104
158
IMPELLER , Replaced By: A3522004304
158
IMPELLER , Replaced By: A3522004504
158
IMPELLER PARTS KIT,760549
166
GASKET KIT , Replaced By: A3442000201
166
GASKET KIT , Replaced By: A3522001060
166
GASKET KIT , Replaced By: A3532002601
166
GASKET KIT WATER PUMP
166
GASKET KIT WATER PUMP,760549
174
GASKET WATER PUMP TO CYLINDER CRANKCASE
174
GASKET , Replaced By: A3522011680
174
GASKET , Replaced By: A3522011780
174
GASKET WATER PUMP COVER
182
SCREW CONNECTOR TO REAR SHIFTING ROD
190
SCREW. HEXAGON HEAD BOLT TRANSMISSION CASE M10X80
198
GASKET1 MM
198
GASKET , Replaced By: A3522032380
999
SEAL , Replaced By: A0002016619
999
SEAL , Replaced By: A0002017219
999
WATER PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 740566, Replaced By: A3532000401
999
COVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 740566, Replaced By: A3522011803
999
HOUSING , Replaced By: A3522031473
999
REPAIR KIT , Replaced By: A3522000560
999
REPAIR KIT , Replaced By: A3522001604
999
WASHER , Replaced By: N000125008443
