Поз.
Артикул
Описание
160
FRONT BUMPER FACE BAR CENTRAL
164
FRONT BUMPER FACE BAR LEFT
168
REINFORCEMENT
172
REPAIR KIT , Replaced By: A1268800997
172
REPAIR KIT , Replaced By: A1168800397
172
SEAL REPAIR KIT
176
BUMPER JOINT COVER LATERAL LEFT
180
SCREW BRACKET TO FENDER,K 104588
184
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
184
SCREW , Replaced By: N304017008016
188
SPRING WASHER , Replaced By: N000137008212
188
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
202
WASHER EXHAUST MUFFLER TO STRAP
202
WASHER , Replaced By: N000125008443
204
NUT , Replaced By: N304032008006
204
NUT
208
RAIL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A1168850221
208
RAIL FRONT 2674 MM
212
FRONT BUMPER FACE BAR LEFT
216
RAIL FRONT LEFT AND RIGHT 1346 MM
216
RAIL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A1168850321
220
NUT RETAINER , Replaced By: A3229900091
224
SCREW PUMP TO BRACKET
224
SCREW COVER PLATE TO BRACKET
228
WASHER , Replaced By: N009021006208
228
WASHER COMPRESSED AIR LINE TO BRACKET
232
SCREW , Replaced By: N304017008016
232
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
236
SPRING WASHER , Replaced By: N000137008212
236
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
240
SEAL RINGZYLINDER VERDECK AN SAEULE
244
WASHER , Replaced By: N000125008443
244
WASHER EXHAUST MUFFLER TO STRAP
248
NUT , Replaced By: N304032008006
248
NUT
252
SHEET METAL SCREW , NOT USED
256
WASHER COMPRESSED AIR LINE TO BRACKET
256
WASHER , Replaced By: N009021006208
260
BRACKET INSIDE LEFT
264
BRACKET OUTSIDE LEFT
268
BRACKET OUTSIDE LATERAL LEFT
272
SCREW PIPE CLAMP
272
SCREW , Replaced By: N304017008021
276
WASHER , Replaced By: A6312670276
276
WASHER FENDER BRACKET TO FENDER, Replaced By: A0049902582
276
WASHER FENDER BRACKET TO FENDER
280
SCREW , Replaced By: N304017008034
280
SCREW BRACKET TO CROSS CONNECTION STRUT
284
WASHER BRACKET TO CAB REAR PANEL
284
WASHER , Replaced By: N009021008213
284
WASHER BRACKET TO LEFT SIDE MEMBER
288
WASHER , Replaced By: N009021010209
288
WASHER BRACKET TO COVERING
292
NUT BRACKET TO SUPPORT AND TO END PIECE
292
NUT BATTERY CABLE
296
PLUGTO 123 880 12 70
300
REAR BUMPER FACE BAR REAR CENTRAL
304
REAR BUMPER FACE BAR REAR LEFT
308
REPAIR KIT , Replaced By: A1268800897
308
REPAIR KIT , Replaced By: A1168800497
308
SEAL REPAIR KIT
312
REINFORCEMENT
316
BUMPER JOINT COVER REAR
320
SCREW BRACKET TO FENDER,K 104588
324
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
324
SPRING WASHER , Replaced By: N000137008212
328
SCREW , Replaced By: N304017008016
328
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
332
WASHER , Replaced By: N000125008443
332
WASHER EXHAUST MUFFLER TO STRAP
336
NUT , Replaced By: N304032008006
336
NUT
340
BRACKET
344
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
344
SCREW , Replaced By: N304017008016
348
WASHER , Replaced By: N009021008213
348
WASHER BRACKET TO LEFT SIDE MEMBER
348
WASHER BRACKET TO CAB REAR PANEL
352
RAIL FRONT 2674 MM
356
PAD
360
SCREW , Replaced By: N304017008021
360
SCREW PIPE CLAMP
364
WASHER , Replaced By: N009021008213
364
WASHER BRACKET TO LEFT SIDE MEMBER
364
WASHER BRACKET TO CAB REAR PANEL
368
NUT BATTERY CABLE
368
NUT BRACKET TO SUPPORT AND TO END PIECE
372
WASHER , Replaced By: N009021010209
372
WASHER BRACKET TO COVERING
376
REAR BUMPER FACE BAR REAR LEFT
380
RAIL FRONT LEFT AND RIGHT 1346 MM
384
PAD
388
COMBINATION BOLTBEI GETRIEBE AUTOMATISCH 4-GANG
392
PAD
396
SCREW PIPE CLAMP
396
SCREW , Replaced By: N304017008021
398
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
999
ADHESIVE TAPE , Replaced By: A0019875646
999
WASHER
999
LOCK
999
LOCK GRILLE TO RADIATOR GRILLE SHELL,TOP LATERAL
999
CLIP , Replaced By: A0019942745
999
CLIP , Replaced By: A0019942745
999
REPAIR KIT , Replaced By: A1155860288
999
STOP SCREW , Replaced By: A2019880211
999
ENGINE HOOD CATCH , Replaced By: A1158870006
999
ENGINE HOOD CATCH , Replaced By: A1158800160
999
WASHER
999
REPAIR KIT , Replaced By: A1158800160
999
PAD 2 MM
999
SPRING , Replaced By: A1158880334
999
GARNISH MOULDING , 100001
999
REPAIR KIT , Replaced By: A1268800597
999
REPAIR KIT , Replaced By: A1165860788
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 060174 024,025 057819 028,029 032088 032,033 046525 036 000442, Replaced By: A1165860888
999
REPAIR KIT , Replaced By: A1165860888
999
ENGINE HOOD , UP TO CHASSIS: 020 016633 024 018944 028 017166 032,033 017083, Replaced By: A1168800257, +002N912002014000
999
SEAL FRONT FENDER, UP TO CHASSIS: 020 061497 024,025 058877 028,029 032404 032,033 047008 036 000510
999
ENGINE HOOD , UP TO CHASSIS: 020 016633 024 018944 028 017166 032,033 017083, Replaced By: A1168800257, +002N912002014000
999
ENGINE HOOD RELEASE CABLE , Replaced By: A1168800259
999
MERCEDES BADGE , TO BE ADAPTED DURING ASSEMBLY UP TO CHASSIS: 020 043454 024,025 043534 028,029 027251 032,033 038844, Replaced By: A1168800288
999
FRONT FENDER RIGHT
999
FRONT BUMPER FACE BAR RIGHT
999
SUPPORT RIGHT
999
GARNISH MOULDING RIGHT
999
ENGINE HOOD STEEL
999
SAFETY HOOK RIGHT
999
REAR BUMPER FACE BAR REAR RIGHT
999
FRONT BUMPER FACE BAR RIGHT
999
REAR BUMPER FACE BAR REAR RIGHT
999
GARNISH MOULDING RIGHT FRONT
999
PAD TOP RIGHT
999
PAD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 061497 024,025 058877 028,029 032404 032,033 047008 036 000510, Replaced By: A0039895485
999
GARNISH MOULDING RIGHT LATERAL
999
PARTITION PANEL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 049530 024,025 049669 028,029 028836 032,033 041548 036 000011, Replaced By: A1168840535
999
PANELLING , Replaced By: A1168840948
999
PARTITION PANEL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 049530 024,025 049669 028,029 028836 032,033 041548 036 000011, Replaced By: A1168840635
999
PANELLING , Replaced By: A1168841048
999
PARTITION PANEL RIGHT
999
PANELLING RIGHT, BELOW LIGHTING UNIT, TO BE ADAPTED DURING ASSEMBLY
999
BUMPER JOINT COVER LATERAL RIGHT
999
BRACKET INSIDE RIGHT
999
BRACKET OUTSIDE RIGHT
999
BRACKET OUTSIDE LATERAL RIGHT
999
SPRING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 003317 024 003333 028 003901 032,033 000052, Replaced By: A1168870279
999
LEVER , Replaced By: A1168870474
999
LEVER RIGHT
999
RADIATOR GRILLE SHELL , UP TO CHASSIS: 020 011952 024 013313 028 013180 032,033 010270, Replaced By: A1168880515, +002A1158880334, +002A1169870439, +002N007981004219
999
GRILLE RIGHT
999
RADIATOR GRILLE SHELL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 020 011953-043454 024,025 013314-043534 028,029 013181-027251 032,033 010271-038844 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 036 000008, Replaced By: A1168880515
999
REPAIR KIT , Replaced By: A1168800097
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SHEET METAL SCREW , Replaced By: A0009906836
