Поз.
Артикул
Описание
12
DOOR SHELL RIGHT
14
DOOR CHECK
16
SCREW
23
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
23
NUT , Replaced By: N913023006001
23
NUT , Replaced By: N910112006001
24
SCREW
26
DOOR LOCK RIGHT, FROM CHASSIS 020 059622 032,033 046285
30
SCREW
30
SCREW , Replaced By: A1409843029
32
INTERIOR HANDLE ASSEMBLY RIGHT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
34
SLEEVE , FROM CHASSIS: 010 083019 110 211691 017,117 000001
36
PULL ROD RIGHT
40
SCREW
42
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
44
NUT RETAINER , Replaced By: A3229900091
46
CLIP
46
CLIP , Replaced By: A0069886378
50
DOOR LOCKING DEVICE , UP TO CHASSIS 020 103123 024,025 116353 028,029 046767 032,033 081591 036 004355 120 000683, Replaced By: A1167301293, +001A1167330670
50
DOOR LOCKING DEVICE , Replaced By: A1167301193
54
LOCK PULL ROD TO DOOR LOCK
55
CLIP , Replaced By: A0069886378
55
CLIP
56
NUT RETAINER
57
RIVET , Replaced By: A0009906092
57
RIVET UPPER PART
58
LOCKING EYE RIGHT
60
PLATE0.5 MM
62
PLATE
64
SCREW
66
EDGING RIGHT
68
SCREW
72
ESCUTCHEON RIGHT
74
SEAL
76
SCREW
78
TOOTHED WASHER CABLE TO FUSE BOX
80
INSERT RIGHT
82
KNOB , 023 116973 033 048510 123 097280 130 120563
84
DOOR HANDLE
86
PAD
88
COMBINATION BOLT STEERING SHAFT BEARING TO CAB, Replaced By: N000000001144, +001N000137006204
88
SCREW STEERING SHAFT BEARING TO CAB
90
EXPANSION PLUG
92
PIN
94
WASHER DOOR CHECK TO FRONT PANEL PILLAR
96
LOCK
98
GLASS PANE LEFT REAR DOOR,FIXED
99
GLASS PANE RICHT,REAR DOOR
100
SEAL RIGHT
104
WINDOW RUN , Replaced By: A1167350325
106
SEAL , Replaced By: A1167250198
106
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
110
SEALING RAIL , Replaced By: A1167250065
112
CLIP
118
SEALING RAIL , Replaced By: A1167250065
120
CLIP
126
WINDOW REGULATOR , Replaced By: A1167302246
126
WINDOW REGULATOR RIGHT REAR DOOR
128
SPRING , 123.043 011674 123.050 002995 123.053 014261 FROM CHASSIS SEE STANDARD VERSION
130
ELECTRIC MOTOR RIGHT REAR DOOR
130
ELECTRIC MOTOR , Replaced By: A0018204442
130
ELECTRIC MOTOR , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0018207842
132
WINDOW REGULATOR RAIL RIGHT
134
REPAIR KIT
134
REPAIR KIT , Replaced By: A1237200114
136
NUT BALL PIVOT TO LEVER
138
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
146
WINDOW STAYBAR RIGHT
148
SCREW COVER PLATE TO COVER PLATE M 6 X 10
148
SCREW , Replaced By: N304017006034
150
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
152
WASHER , Replaced By: N009021006208
152
WASHER COMPRESSED AIR LINE TO BRACKET
154
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
156
WASHER , Replaced By: N000125004319
156
WASHER BRACKET TO SUPPORT
170
RUBBER MOULDING 290 MM, 100001
171
RETAINING RAIL RIGHT, NO LONGER AVAILABLE
172
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
173
WINDOW GUIDE
174
SCREW PUMP TO BRACKET
174
SCREW BRACKET TO BEARING BRACKET M 6X16
178
WASHER , Replaced By: N009021006208
178
WASHER COMPRESSED AIR LINE TO BRACKET
180
SCREW PUMP TO BRACKET
180
SCREW BRACKET TO BEARING BRACKET M 6X16
184
WASHER , Replaced By: N009021006208
184
WASHER COMPRESSED AIR LINE TO BRACKET
188
SLIDING JAW LEFT
188
SLIDING JAW , Replaced By: A1167200142
200
SHACKLE
202
SLIDING JAW
204
SCREW BRACKET TO BEARING BRACKET M 6X16
204
SCREW PUMP TO BRACKET
206
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
208
WASHER , Replaced By: N009021006208
208
WASHER COMPRESSED AIR LINE TO BRACKET
999
ELECTRIC MOTOR , Replaced By: A0008207242, +002A0009970181, +002N046236004100
999
ELECTRIC MOTOR , Replaced By: A0008207342, +002A0009970181, +002N046236004100
999
ELECTRIC MOTOR , Replaced By: A0018204542
999
SCREW
999
WASHER LOWER PART
999
SCREW , Replaced By: N914114006007
999
NUT RETAINER , Replaced By: A0009907191
999
ELECTRIC MOTOR , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0018207742
999
ELECTRIC MOTOR LEFT REAR DOOR
999
CLIP , Replaced By: A0069886378
999
INSERT LEFT
999
WASHER
999
RIVET , Replaced By: A0009905548
999
INTERIOR HANDLE ASSEMBLY LEFT, FROM CHASSIS: 010 083019, ALSO INSTALLED ON: 055487-055613 110 211691, ALSO INSTALLED ON: 137775-138117 017,117 000001
999
REPAIR KIT , Replaced By: A1267300114
999
REPAIR KIT , Replaced By: A1165860073
999
LOCKING EYE LEFT
999
WINDOW REGULATOR RAIL LEFT
999
RETAINING RAIL LEFT, NO LONGER AVAILABLE
999
SLIDING JAW RIGHT
999
EDGING LEFT
999
PLATE , Replaced By: A1167230111
999
SEALING RAIL OUTSIDE, FROM CHASSIS 011,060,062 100001
999
PANELLING , Replaced By: A1167350551
999
REPAIR KIT CONVERSION OF REAR DOOR
999
SLIDING JAW , Replaced By: A1167200242
999
WINDOW STAYBAR LEFT
999
DOOR LOCK LEFT
999
WINDOW REGULATOR , Replaced By: A1167302146
999
WEATHERSTRIP LEFT
999
GARNISH MOULDING LEFT
999
PULL ROD LEFT
999
EDGE GUARD SECTION LEFT
999
DOOR LOCK RIGHT
999
DOOR LOCK LEFT, FROM CHASSIS 020 059622 032,033 046285
999
PANELLING FRONT LEFT
999
DOOR LOCKING DEVICE , UP TO CHASSIS 020 103123 024,025 116353 028,029 046767 032,033 081591 036 004355 120 000683, Replaced By: A1167301193, +001A1167330570
999
CRANK OPERATED WINDOW LEFT,REAR DOOR
999
PANELLING LEFT
999
CRANK OPERATED WINDOW RICHT,REAR DOOR
999
PANELLING LEFT,REAR DOOR, WHEN ORDERING STATE VERSION OF DOOR INSIDE VELOURS LINING,PLAIN OR CORDED ANTHRACITE GREY NO.7066 CODE 961,ANTHRACITE NO.7081 CODE 901,BLUE NO.5032 CODE 962, BLUE NO.5050 CODE 902, MAHOGANY NO.8150 CO DE 963,BEIGE NO.8149 CODE 964 AND FOOTN.25
999
DOOR LOCKING DEVICE LEFT, FROM CHASSIS 020 103124 024,025 116354 028,029 046768 032,033 081591 036 004356 120 000684
999
PANELLING RICHT,REAR DOOR, WHEN ORDERING STATE VERSION OF DOOR INSIDE VELOURS LINING,PLAIN OR CORDED ANTHRACITE GREY NO.7066 CODE 961,ANTHRACITE NO.7081 CODE 901,BLUE NO.5032 CODE 962, BLUE NO.5050 CODE 902, MAHOGANY NO.8150 CO DE 963,BEIGE NO.8149 CODE 964 AND FOOTN.25
999
PANELLING LEFT,REAR DOOR, BLACK NO.9007 CODE 101,161,201,261,DARK BLUE NO.5031 CODE 162,262,BLUE NO.5045 CODE 102,202 AND FOOTN.11
999
PANELLING REAR LEFT
999
WINDOW REGULATOR LEFT REAR DOOR
999
DOOR SHELL LEFT
999
PANELLING INSIDE LEFT REAR DOORS, WHEN ORDERING STATE VERSION OF DOOR INSIDE VELOURS LINING,PLAIN OR CORDED ANTHRACITE GREY NO.7066 CODE 961,ANTHRACITE NO.7081 CODE 901,BLUE NO.5032 CODE 962, BLUE NO.5050 CODE 902, MAHOGANY NO.8150 CO DE 963,BEIGE NO.8149 CODE 964 AND FOOTN.25
999
PANELLING INSIDE RIGHT REAR DOORS, WHEN ORDERING STATE VERSION OF DOOR INSIDE VELOURS LINING,PLAIN OR CORDED ANTHRACITE GREY NO.7066 CODE 961,ANTHRACITE NO.7081 CODE 901,BLUE NO.5032 CODE 962, BLUE NO.5050 CODE 902, MAHOGANY NO.8150 CO DE 963,BEIGE NO.8149 CODE 964 AND FOOTN.25
999
PANELLING INSIDE LEFT REAR DOORS, BLACK NO.9007 CODE 101,161,201,261,DARK BLUE NO.5031 CODE 162,262,BLUE NO.5045 CODE 102,202 AND FOOTN.11
999
LINK LEFT, FROM CHASSIS 020 103124 024,025 116354 028,029 046768 032,033 081591 036 004356 120 000684
999
LINK RIGHT, FROM CHASSIS 020 103124 024,025 116354 028,029 046768 032,033 081591 036 004356 120 000684
999
SEAL LEFT
999
BINDING RAIL WINDOW INNER MOULDING,LEFT REAR DOOR, STATE COLOR NUMBER WHEN ORDERING
999
WINDOW RUN1575 MM
999
GARNISH MOULDING LEFT
999
GARNISH MOULDING FRONT LEFT
999
GARNISH MOULDING LEFT
999
GARNISH MOULDING TOP LEFT
999
ESCUTCHEON LEFT
999
REPAIR KIT , Replaced By: A1167300014
999
SCREW BRACKET TO BEARING BRACKET M 6X16
999
SCREW
