Поз.
Артикул
Описание
200
ALTERNATOR14V/65A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
204
SCREW
204
SCREW , Replaced By: A0019900821
204
SCREW HOUSING
206
GROOVED BALL BEARING , Replaced By: N000625436303
206
GROOVED BALL BEARING
206
BALL BEARINGTO 005 154 32 02
210
GROOVED BALL BEARING
210
BALL BEARINGTO 005 154 34 02
214
CARBON BRUSH SET
220
REPAIR KIT
220
REPAIR KIT ROTOR TO 005 154 52 02
222
SPRING
224
SPRING
228
DIODE
234
DIODE POS.
244
CONDENSER
248
RECTIFIERTO 005 154 83 02,006 154 67 02
252
SCREW T-FITTING TO BRACKET M4X25
254
SPRING WASHER ALTERNATOR CONNECTION D+
256
REGULATORTO 007 154 26 02
256
REGULATOR AND CUT-OUT , Replaced By: A0001541805
256
REGULATOR AND CUT-OUT , Replaced By: A0001541805
256
REGULATOR AND CUT-OUTTO 005 154 32 06
258
SCREW , Replaced By: N007985004130
258
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
260
SPRING WASHER ALTERNATOR CONNECTION D+
262
SEAL RINGTO 005 154 34 02
264
GASKET
266
CONDENSER
270
SPRING WASHER ALTERNATOR CONNECTION W
270
SPRING WASHER ALTERNATOR CONNECTION D+
270
SPRING WASHER HEATER PLUG CABLE HARNESS
272
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
272
NUT RELAY TO BRACKET M5
272
NUT BALL PIVOT TO LEVER
274
BOOT HEATER PLUGS
282
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
284
NUT BRACKET TO SIDE MEMBER
286
WOODRUFF KEY
294
FAN ALTERNATOR
296
FAN WITH PULLEY
306
NUT AIR CLEANER ELEMENT
310
BRACKET
310
BRACKET ALTERNATOR
316
BUSHINGTO 366 150 06 73
316
BUSHING
316
BUSHINGTO 355 150 03 72,366 150 13 72
370
GROUND CABLE GENERATOR TO GENERATOR SUPPORT,529890
376
SPRING WASHER ALTERNATOR CONNECTION D+
378
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
EXCITER COILTO 003 151 87 01
999
STARTING MOTOR12 V,3 KW,LUCAS
999
STARTING MOTOR , Replaced By: A0031518701
999
STARTING MOTORFA. BOSCH
999
ALTERNATOR
999
ALTERNATOR , MB PART NO.003 154 39 02BOSCH PART NO. 0 120 400 700 MB PART NO.005 154 29 02BOSCH PART NO. 0 120 489 723 MB PART NO.005 154 33 02BOSCH PART NO. 0 120 489 725, Replaced By: A0051543302
999
ALTERNATOR , Replaced By: A0071542302, +001A0001557118
999
GROUND CABLE FROM ALTERNATOR TO FRAME SIDE MEMBER, UP TO IDENT NO. 727921 EXCEPT FOR,500001-599999,FROM IDENT NO. SEE ENGINE MICROFICHE
999
GROUND CABLE , Replaced By: A4031500732
999
BUSHING
999
ELECTRIC CABLE , Replaced By: A3521500932
999
SOLENOID SWITCH , Replaced By: A0001527010, +001A0001511849, +003A0009907430
