Поз.
Артикул
Описание
5
CABLE HARNESS MAIN CABLE HARNESS
5
CABLE HARNESS MAIN CABLE HARNESS
5
CABLE HARNESS MAIN CABLE HARNESS
5
CABLE HARNESS
5
CABLE HARNESS MAIN CABLE HARNESS
167
SOCKET (SET POINT SENDER UNIT)
182
FUSE BOX
182
FUSE BOX , 023 016458 033 012019 123 008854 130 014465
191
FUSE BOX DOUBLE
194
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
197
LOCK WASHER T-FITTING TO BRACKET
200
LIGHT SWITCH
203
BOOT LIGHT ROTARY SWITCH
206
SCREW ELECTRIC CABLE TO HORN
209
LOCK WASHER T-FITTING TO BRACKET
221
COVER FUSE BOX
224
MARKING STRIP FUSE BOX
227
NUT TACHOGRAPH TO BRACKET
230
WASHER BOOT TO CAB FLOOR
230
WASHER , Replaced By: N000433005304
233
SWITCH , Replaced By: A1245450114
233
SWITCH WARNING BUZZER
236
HANDLE LIGHT ROTARY SWITCH, 003 112821 007 103308 086 007451 093 010618 102,103 339977 105 280993 183 019383 190 024566 193 007303 200 107837 280 003323 283 008566
236
HANDLE LIGHT ROTARY SWITCH, 033 103308 130 280993 223 107837
239
SHELL , 003 112822 007 103309 086 007452 093 010619 102,103 339978 105 280994 183 019384 190 024567 193 007304 200 107838 280 003324 283 008567
242
NUT WIRE CABLE TO INSTRUMENT PANEL
245
BULB LIGHTING OF LEFT AND RIGHT OPERATING UNITS AND BLOWER SWITCH
245
BULB , Replaced By: N000000001061
245
BULB , Replaced By: A0008250094
248
SWITCH , Replaced By: A2018202110
248
SWITCH DOOR CONTACT
260
CLIP CONTROL UNIT TO BRACKET
266
SCREW COVER PLATE TO BRACKET
266
SCREW PUMP TO BRACKET
269
SPRING WASHER LICENSE PLATE TO BRACKET
272
SCREW TAIL LAMP GROUND CABLE TO WHEEL ARCH PANEL
275
LOCK WASHER T-FITTING TO BRACKET
278
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SHELL , Replaced By: A6015450291
