Поз.
Артикул
Описание
5
ELECTRIC MOTOR REAR PANEL DOOR PANE WIPER, 083 006081 086 004624 093 005619 183 010007 190 015181
5
ELECTRIC MOTOR REAR PANEL DOOR PANE WIPER, 083 006082 086 004625 093 005620 183 010008 190 015182
8
ELECTRIC MOTOR , 083 006081 086 004624 093 005619 183 010007 190 015181
8
ELECTRIC MOTOR , 083 006082 086 004625 093 005620 183 010008 190 015182
11
PLUG , Replaced By: A0035457128
11
PLUG , Replaced By: A0065457828, +006A0015453826, +001A0095453028
14
ROD WIPER MOTOR TO REAR PANEL DOOR
17
BUSHING WIPER MOTOR TO REAR PANEL DOOR
20
RING WIPER MOTOR TO REAR PANEL DOOR
20
LOCK HOOK , Replaced By: A0008240783
23
SLEEVE WIPER SPINDLE
26
COMBINATION BOLT
29
BUSHING
32
GROMMET
32
GROMMET , Replaced By: A0089979781
32
GROMMET , Replaced By: A1249970681
35
COMBINATION BOLT , Replaced By: N304017006020, +001N000125006421
35
SCREW LICENSE PLATE TO BRACKET
38
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
38
WASHER , Replaced By: A1089900340
41
CLIP CABLE HARNESS TO WIPER MOTOR PLUG
44
PAD , 083 004326 086 002391 093 004201 183 007380 190 011113
47
ANGLE REAR PANEL DOOR
50
BRACKET POLE HOUSING, 083 004327 086 002392 093 004202 183 007381 190 011114
53
BRACKET WIPER SYSTEM, 083 004327 086 002392 093 004202 183 007381 190 011114
56
COMBINATION BOLT
59
GROMMET CLOCK
62
HOSE
62
HOSE
65
CLIP
68
CLIP
71
WIPER ARM REAR PANEL DOOR PANE WIPER
74
WIPER RUBBER REAR PANEL DOOR PANE WIPER TO 000 820 47 45
74
WIPER BLADE , Replaced By: A0008242227
77
WIPER RUBBER REAR PANEL DOOR PANE WIPER TO 000 820 47 45
80
NUT
80
NUT , Replaced By: N304032008006
83
SPRING WASHER , Replaced By: N000137008212
83
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
