Поз.
Артикул
Описание
5
ELEMENT FRONT DOOR,F 158288
5
ELEMENT FRONT DOOR,F 158288
5
ELEMENT FRONT DOOR,F 158288
11
ROD FRONT DOOR VACUUM ELEMENT
12
PLUG VACUUM ELEMENT AT FILLER NECK FLAP,F 158288
13
HOSE *** 30 MM
14
ELEMENT REAR DOOR
14
ELEMENT REAR DOOR
14
ELEMENT REAR DOOR
15
HOSE *** 30 MM
17
CONTROL ROD. ROD REAR DOOR VACUUM ELEMENT
20
SCREW ELEMENT ON FRONT AND REAR DOORS
21
CAP REAR DOOR ELEMENT
22
SCREW VACUUM ELEMENTS ON LEFT AND RIGHT REAR DOORS
23
HOSE TO ELEMENT AT FRONT SEAT
26
SEAL RING
29
HOSE *** 30 MM
32
RUBBER RING EMERGENCY LANTERN TO CAB
35
HOSE ORDER BY THE METER
38
CLIP
41
CLAMP BOWDEN CABLE TO CAB
44
DISTRIBUTOR MAIN FLOOR,RIGHT
47
DISTRIBUTOR HEATING AND FUEL CONSUMPTION INDICATOR
48
DISTRIBUTOR CENTRAL LOCKING MECHANISM PUMP,RIGHT
50
PUMP INFRARED REMOTE CONTROL & ORTHOPAEDIC FRONT BACKREST
50
PUMP CENTRAL LOCKING MECHANISM, NOT WITH FRONT ORTHOPAEDIC BACKREST
50
PUMP CENTRAL LOCKING MECHANISM, NOT WITH FRONT ORTHOPAEDIC BACKREST, ONLY USED WITH IMMOBILISER
50
PUMP INFRARED REMOTE CONTROL & ORTHOPAEDIC FRONT BACKREST, ONLY USED WITH IMMOBILISER
51
PLUG BLIND PLUG,FOR FREE CONNECTIONS
53
CAP BOTTOM AND TOP
54
DISTRIBUTOR WITH 7 CONNECTIONS
54
DISTRIBUTOR WITH 11 CONNECTIONS
56
ELEMENT FILLER NECK FLAP,F 158288
56
ELEMENT FILLER NECK FLAP,F 158288
59
ROD FILLER NECK FLAP ELEMENT,A 012 992
60
PLUG VACUUM ELEMENT AT FILLER NECK FLAP,F 158288
61
HOSE *** 30 MM
62
SCREW ELEMENT ON FRONT AND REAR DOORS
65
GUIDE FILLER NECK RECESS,F 158287
68
ELEMENT REAR PANEL DOOR
68
ELEMENT REAR PANEL DOOR
68
ELEMENT REAR PANEL DOOR
68
ELEMENT REAR LID ADDITIONAL LOCKING MECHANISM
74
ROD REAR LID ELEMENT
75
PLUG VACUUM ELEMENT AT FILLER NECK FLAP,F 158288
76
HOSE *** 30 MM
77
SCREW ELEMENT ON FRONT AND REAR DOORS
80
DISTRIBUTOR HEATING AND FUEL CONSUMPTION INDICATOR
83
HOSE *** 30 MM
83
HOSE TO ELEMENT AT FRONT SEAT
84
DISTRIBUTOR AIR CONDITIONER + ADJUSTABLE HEADREST + TWO SELECTION PROGRAMMES 7-FACH
85
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
86
HOSE ORDER BY THE METER
89
CLIP TAIL LAMP CABLE HARNESS TO REAR LID
92
GROMMET TAIL LAMP CABLE HARNESS THRU REAR PANEL
92
GROMMET
95
COVERING REAR-LID-LOCK CONTROL ROD
98
SCREW ELEMENT ON FRONT AND REAR DOORS
101
CLIP LIGHT-RANGE-REGULATOR VACUUM LINE
101
CLIP ENGINE HOOD RELEASE CABLE TO FRONT PANEL,BOTTOM
112
ADHESIVE TAPE70X70
113
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
113
LOOM TIE
