Поз.
Артикул
Описание
9
STARTING MOTOR24 V/4 KW, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
9
STARTING MOTOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041515901
9
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 325960YEAR OF MANUFACTURE 1993 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041518601
18
EXCITER COILTO 001 151 96 01
22
EXCITER COILTO 003 151 86 01
22
EXCITER COIL , Replaced By: A0001519255
22
EXCITER COIL , Replaced By: A0001519255
22
EXCITER COILTO 003 151 04 01/74 01/88 01
24
ARMATURETO 001 151 96 01
30
CARBON BRUSH SETTO 001 151 96 01
36
CARBON BRUSH SET
45
SPRINGTO 004 151 58 01
45
SPRINGTO 003 151 87 01
52
PINION , Replaced By: A0011510213
52
PINIONTO 004 151 58 01/003 151 87 01
52
PINIONTO 001 151 96 01
52
PINIONTO 003 151 04 01/74 01
60
BUSHING STARTER PINION TO 004 151 58 01/003 151 87 01
65
BUSHING STARTER PINION TO 003 151 04 01/74 01
65
BUSHINGTO 004 151 58 01
65
BUSHING STARTER PINION TO 001 151 96 01
74
BUSHINGTO 004 151 58 01/003 151 87 01
86
BUSHINGTO 004 151 58 01
86
BUSHINGTO 001 151 96 01
92
REPAIR KIT , Replaced By: A0005865615
93
REPAIR KIT , Replaced By: A0001500572
93
REPAIR KITTO 003 151 04 01/74 01
93
CLAMPING BOLT ARMATURE TO 004 151 58 01/003 151 87 01
95
SEAL RINGTO 001 151 96 01
95
SEAL RINGTO 001 151 96 01
98
SPRINGTO 001 151 96 01
98
SPRINGTO 001 151 96 01
999
TERMINAL TERMINALS: B+, B-, D+, W
999
CONTROL LEVERTO 001 151 96 01
999
CONTROL LEVERTO 004 151 58 01/003 151 87 01
999
BEARINGTO 004 151 58 01
999
SOLENOID SWITCHTO 003 151 04 01/74 01,001 151 96 01
999
SOLENOID SWITCHTO 003 151 86 01/88 01,004 151 59 01
999
BUSHING ALTERNATOR MOUNTING FOOT TO 005 154 33 02
999
FAN
999
FAN ALTERNATOR
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
SCREWTO 003 151 87 01
999
SCREW , Replaced By: A0009908221
999
SCREWTO 003 151 87 01
999
SCREW REGULATOR MOUNTING TO 009 154 07 02
999
SCREW , Replaced By: A0009909721
999
SCREW , Replaced By: A0019900821
999
SCREWTO 004 151 58 01
999
SCREW , Replaced By: A0009907921
999
SCREW
999
SCREWTO 003 154 33 02
999
SCREW
999
STARTING MOTOR
999
PULLEY , Replaced By: A0011551015
999
PULLEY TWO-GROOVE,208848/91, Replaced By: A0011555815
999
BELT PULLEY F POLY-V BELT TWO-GROOVE,208848/91
999
PLUG SOCKET , Replaced By: A0005453726
999
DIODE , Replaced By: A0015481518
999
DIODE
999
SCREW , Replaced By: A0019902120
999
SCREWTO 003 151 86 01/88 01
999
SCREW , Replaced By: A0009909621
999
SCREWTO 004 151 58 01
999
PIN BUSHING HOUSING 3-POLE,4 483482
999
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 105724, Replaced By: A0031517401
999
STARTING MOTOR , Replaced By: A0031518601
999
STARTING MOTOR , Replaced By: A0031518801
999
ALTERNATOR , Replaced By: A0031547502
999
ALTERNATOR
999
V-BELT
999
V-BELT
999
V-BELT SET2 PIECES
999
V-BELT FAN DRIVE,D 180260
999
PLUG , Replaced By: A0015457726
999
V-BELT
999
ALTERNATOR , MB PART NO.003 154 39 02BOSCH PART NO. 0 120 400 700 MB PART NO.005 154 29 02BOSCH PART NO. 0 120 489 723 MB PART NO.005 154 33 02BOSCH PART NO. 0 120 489 725, Replaced By: A0051543302
999
ALTERNATOR , Replaced By: A0071542602
999
V-BELT , Replaced By: A0059973092
999
BUSHING
999
INTERMEDIATE PIECE
999
FAN
999
FAN
999
BUSHINGTO 366 150 06 73
999
BUSHINGTO 355 150 03 72,366 150 13 72
999
BUSHING
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SPRING WASHER HEATER PLUG CABLE HARNESS
999
SPRING WASHER ALTERNATOR CONNECTION W
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
NUT WEAR INDICATOR
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
999
SCREW , Replaced By: N007985004130
999
SCREW T-FITTING TO BRACKET M4X25
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT
