Mercedes A1248320988 - Шланг

E 320 JAPAN FROM 09/89 124.032

82 ELECTRICAL SYSTEM - 001 READING LAMP ON ROOF RAIL AND LAMP ABOVE REAR WINDOW PANE IL.1

Поз.
Артикул
Описание
110
A1268301472
TEMPERATURE SENSOR INBOARD, ON ROOF RAIL
113
A0008309608
BLOWER , Replaced By: A0008301908
113
A0008301908
BLOWER
116
A1248355814
BRACKET AT BLOWER,TEMPERATURE SENSOR VENTILATION, ONLY USED WITH SLIDING ROOF
119
N914136004203
SCREW
122
A1248321088
HOSE BETWEEN ROOF RAIL MOUNTED TEMPERATURE FEELER HOSE AND BLOWER, ONLY USED WITH SLIDING ROOF
125
A1268350393
INTERMEDIATE LAYER AT BLOWER,TEMPERATURE SENSOR VENTILATION
128
A1269901036
SCREW , Replaced By: A2039900036
135
A1248320988
HOSE , TO BE ADAPTED DURING ASSEMBLY
137
A1248320027
CONNECTOR BETWEEN ROOF RAIL MOUNTED TEMPERATURE FEELER & AIR-BLAST NOZZLE
140
A1269885278
CLIP TEMPERATURE-SENSOR AIR-GUIDE HOSE TO FRONT ROOF RAIL
143
A1248320099
RING
