Поз.
Артикул
Описание
5
CABLE HARNESS HEADLAMP, FROM MODEL YEAR 93
5
CABLE HARNESS HEADLAMP, UP TO END OF MODEL YEAR 92
8
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
11
COVER , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
14
PIN BUSHING HOUSING 4-POLE, BLOWER MOTOR
14
PLUG TRIPLE
23
PIN BUSHING HOUSING FUSE BOX
24
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
25
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
26
COVERTO 006 545 81 28
27
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
33
PLUG HOUSINGADS-ASD
34
PLUG PIN
40
PIN BUSHING HOUSING TELL-TALE LAMP ASD
41
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
42
PIN BUSHING HOUSING LAMP CONTROL DEVICE,8-POLE
43
ROUND PIN BUSHING2.5 MM2
51
GROMMET ELECTRIC CABLE THRU FUSE BOX AND RELAY CASE
54
GROMMET
57
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
60
SCREW TAIL LAMP GROUND CABLE TO WHEEL ARCH PANEL
63
LOCK WASHER T-FITTING TO BRACKET
66
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
87
SCREW ELECTRIC CABLE TO HORN
90
LOCK WASHER T-FITTING TO BRACKET
93
HORNHELLA,500 HZ
93
HORNHELLA,400 HZ,B 859136
99
BRACKET TRUMPET HORN IN RIGHT WHEELHOUSE
102
BRACKET TRUMPET HORN IN FRONT OF RADIATOR, UP TO END OF MODEL YEAR 92
103
BRACKET TRUMPET HORN IN FRONT OF RADIATOR, ONLY USED WITH AIR CONDITIONERF 241918
105
SCREW SPEED SENSOR TO REAR AXLE
105
SCREW PIPE ELBOW TO BRACKET M8X12
108
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
114
NUT COVERING TO RAIL
