Поз.
Артикул
Описание
5
CABLE HARNESS INBOARD,WITH AIR CONDITIONING AUTOMATICS,B 587249B 840526
5
CABLE HARNESS INBOARD,WITH AIR CONDITIONING AUTOMATICS,B 840527C 013141
5
CABLE HARNESS INBOARD,WITH AIR CONDITIONING AUTOMATICS,C 013142
8
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
9
COVERTO 011 545 10 28
14
PIN BUSHING HOUSING BIPOLAR
16
PIN BUSHING HOUSING DIODE
17
ROUND PIN BUSHING4 MM2
19
PIN BUSHING HOUSING BIPOLAR
20
COVERTO 010 545 10 28
26
PIN BUSHING HOUSING DOME LIGHTING
29
PIN BUSHING HOUSING CONTROL UNIT
32
PIN BUSHING HOUSING INSTRUMENT CLUSTER,15-POLE
33
COVERTO 010 545 04 28
36
PIN BUSHING HOUSINGTO 014 545 64 28
37
COVER LIGHT SWITCH
40
PIN BUSHING HOUSING CIRCULATING AIR SWITCH, 7-POLE
47
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
48
COVERTO 019 545 29 28
49
PIN BUSHING HOUSING VALVE STRIP,8-POLE
50
PIN BUSHING HOUSING HAZARD WARNING LIGHT, 8-POLE
53
PIN BUSHING HOUSING SWITCH
56
CASE 4-POLE
59
PIN BUSHING HOUSING RELAY CLUSTER
62
PIN BUSHING HOUSING LAMP CONTROL
65
PIN BUSHING HOUSING CRYOSTAT
65
PIN BUSHING HOUSING PRE-GLOW TIME RELAY, 6-POLE
66
ROUND PIN BUSHING2.5 MM2
70
PIN BUSHING HOUSING SOLENOID VALVE,F 051968
71
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
83
PIN BUSHING HOUSING
84
COVERTO 009 545 83 28
85
PIN BUSHING
91
PIN BUSHING HOUSING BIPOLAR
92
FLAT PIN BUSHING , Replaced By: A0075458426
93
PIN BUSHING HOUSING STEERING COLUMN MOUNTED CABLE HARNESS, 14-POLE
94
COVERTO 009 545 23 28
96
PIN BUSHING HOUSING IGNITION/STARTING SWITCH,7-POLE
99
COVERTO 009 545 73 28,
100
PIN BUSHING HOUSING HEADLAMP,WIPER MOTOR,BLOWER SWITCH
103
PIN BUSHING HOUSING BIPOLAR
106
PIN BUSHING HOUSING BIPOLAR
109
PLUG TRIPLE
109
PIN BUSHING HOUSING 4-POLE, BLOWER MOTOR
110
COVERTO 007 545 00 28
113
PIN BUSHING HOUSING 4-POLE
114
COVER
117
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
118
COVERTO 006 545 81 28
121
PIN BUSHING HOUSING 12-POLE
122
COVERTO 009 545 26 28
125
PIN BUSHING HOUSING REFRIGERANT COMPRESSOR
127
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
128
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
129
COVERTO 006 545 81 28
130
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
131
PIN BUSHING HOUSING DIAGNOSIS BOX
132
ROUND PIN BUSHING LIGHT SWITCH
133
PLUG DOOR CABLE HARNESS SEPARATION POINT
134
PLUG DOOR CABLE HARNESS SEPARATION POINT
135
FLAT PLUG1.5-1.0 MM2
136
PIN BUSHING RADIO SET
137
INSULATING SLEEVETO 000 546 43 40
143
CABLE SHOE. PIN BUSHING PRESSURE SWITCH
144
INSULATING SLEEVETO 000 546 83 40
149
GROMMET BRANCH-OFF TO WINDSHIELD WIPER
152
GROMMET
152
GROMMET FIRE WALL,RIGHT
155
SOCKET
155
SOCKET
158
BULB LIGHTING OF LEFT AND RIGHT OPERATING UNITS AND BLOWER SWITCH
158
BULB , Replaced By: N000000001061
161
FASTENER BUTTON ELECTRIC CABLE TO FIRE WALL
170
SHEET METAL SCREW BRACKET TO CAB
173
CLIP WIRE CABLE TO AIR CLEANER
176
SCREW PUMP TO BRACKET
179
SPRING WASHER LICENSE PLATE TO BRACKET
203
BRACKET TIMER IN HOUSING BELOW ASHTRAY
206
BRACKET AIR CONDITIONER CASE,RIGHT
209
SOCKET-TERMINAL STRIP BIPOLE, TERMINAL 58D
212
SCREW ELECTRIC CABLE TO FUSE BOX
215
LOCK WASHER T-FITTING TO BRACKET
