200 TE / E 200 200-320 FROM 10/92, 250D-300D FROM 7/93
124.079
32 SPRINGS,SUSPENSION AND HYDRAULICS
015 SPRINGS AND SUSPENSION,FRONT IL. 2

Mercedes N000125008443 - ШАЙБА

200 TE / E 200 200-320 FROM 10/92, 250D-300D FROM 7/93 124.079

32 SPRINGS,SUSPENSION AND HYDRAULICS - 015 SPRINGS AND SUSPENSION,FRONT IL. 2

Поз.
Артикул
Описание
5
A1244604516
STEER. COLUMN JACKET TUBE OUTSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
5
A1244602716
STEER. COLUMN JACKET TUBE OUTSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
8
N000912006066
SCREW BEARING BRACKET TO TRANSMISSION
8
N000912006097
SCREWM 6X16
11
N000433006405
WASHER BRACKET TO HEAT SHIELD
14
A1244621220
STEER.COLUMN JACKET TUBE INSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
14
A1264621620
STEER.COLUMN JACKET TUBE , Replaced By: A1244621220
14
A1264621720
STEER.COLUMN JACKET TUBE INSIDE, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
17
N000933006103
SCREW , Replaced By: N304017006018
17
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
20
A1244622539
BRACKET BLINKER SWITCH, ONLY APPLICABLE TO ELECTRICALLY ADJUSTABLE STEERING COLUMN
23
N007985006139
SCREW OIL TANK TO BRACKET
26
N000433006405
WASHER BRACKET TO HEAT SHIELD
62
A1269931226
DISC SPRING , Replaced By: A1244600422
62
A1264620362
THRUST WASHER , Replaced By: A1244600422
62
A1244600422
CLAMPING PIECE
68
N000472021000
LOCK RING21 MM
71
A1264620571
SCREW
74
A1264600325
GEARING
77
A1264622274
PIN
80
N912001008000
LOCK HOSE FASTENING
83
N000125008418
WASHER , Replaced By: N000125008443
83
A6210710152
SPACER WASHER , Replaced By: N000125008418
83
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
104
N000912006175
SCREW , Replaced By: A0019907212
104
N000912006025
SCREW , Replaced By: N000912006175
104
A0019907212
SCREW SHIM TO LEAF SPRING
