Поз.
Артикул
Описание
5
SOCKET-TERMINAL STRIP SPEED TRANSMITTER
8
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
9
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
11
BRACKET CONTROL UNIT
14
BRACKET MULTIWAY CONNECTOR
17
NUT BALL PIVOT TO LEVER
20
SHEET METAL SCREW ALARM UNIT TO STRUT
23
SENDER UNIT SPEED TRANSMITTER
26
CABLE HARNESS HALL SENDER UNIT
28
PIN BUSHING HOUSING STOP LIGHT SWITCH
29
ROUND PIN BUSHING2.5 MM2
34
SHAFT2000 MM, NOT FOR R.S.A.
34
SHAFT1480 MM
36
GROMMET FLEXIBLE SHAFT THRU FIRE WALL,F 128718
36
BOOT FLEXIBLE SHAFT THRU FIRE WALL
37
SCREW 3/2-WAY VALVE TO BRACKET
39
SPRING WASHER LICENSE PLATE TO BRACKET
41
BRACKET FLEXIBLE SHAFT TO BELL HOUSING
44
BRACKET FLEXIBLE SHAFT TO TRANSMISSION, IN CASE OF REPAIR,REMOVE PARTS FOR ODOMETER AND REPLACE BY SPEEDOMETER SHAFT (REFER TO STANDARD MICROFICHE)
58
CLIP FLEXIBLE SHAFT TO TRANSMISSION,B 670084
62
BRACKET FLEXIBLE SHAFT TO PARKING BRAKE SUPPORT
65
PROTECTIVE TUBE SPEEDOMETER CABLE TO CONSOLE
68
SHEET METAL SCREW SEAT HEATER CONTROL TO CROSS MEMBER AND TO FRONT SEAT
