Поз.
Артикул
Описание
5
PRESSURE GAUGE
7
HOSE FROM WARNING INDICATOR TO AIR CLEANER, ORDER BY THE METER
7
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
10
FITTING
14
UNION NUT
19
SEAL CONE FUEL LINE TO CYLINDER HEAD,689885
23
FITTING LINE CONNECTION
28
ADAPTER FITTING FUEL LINE
36
UNION NUT
42
FITTING , Replaced By: A0029975872
999
OIL PRESSURE GAUGE
999
ELBOW FITTING
999
BRACKET
999
FITTING
999
ELECTRIC CABLE
999
THREADED UNION OIL LINE TO CONNECTOR
999
PIPE ELBOW
999
FITTING OIL PASSAGE PLUG
999
FITTING , Replaced By: A3529970271
999
FITTING
999
HOSE
999
HOSE
999
SCREW DIODE CASE
999
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SEAL RING LINE CONNECTION
999
SEAL RING LINE CONNECTION
999
SEAL RING , Replaced By: N007603012111
999
SEAL RING LINE CONNECTION
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING VALVE TO VALVE,K 025179
999
SEAL RING
999
CLAMP WIRE CABLE TO ENGINE
999
UNION NUT
999
ADAPTER FITTING
999
SCREW FITTING AIR COMPRESSOR OIL FEED
999
SEAL RING FUEL LINE TO FEED PUMP
999
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
999
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
