Поз.
Артикул
Описание
5
HOSE TOP
8
LOOM TIE
8
CLAMP , Replaced By: A0069970590
11
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.F 052097, Replaced By: A1245013582
11
HOSE BOTTOM, USED WITHOUT ADDITIONAL HEATER
14
HOSE BOTTOM,B 108794
17
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
17
CLAMP , Replaced By: N000000000667
23
CLAMP , Replaced By: A0069974290
23
CLAMP HOSE FASTENING 28-35 MM,V 207570
41
TANK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1245001149
41
TANK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. B 773822, Replaced By: A1245001849
41
TANK EXPANSION TANK
44
SWITCH COOLING WATER LEVEL INDICATOR
47
SEAL RING
50
LOCK RING MAIN SHAFT,FRONT
53
CLOSING COVER RADIATOR
53
FILLER CAP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 205503, Replaced By: A1245000406
56
RUBBER MOUNTING EXPANSION TANK TO WHEELHOUSE
59
NUT , Replaced By: A0039905351
59
NUT MOUNTING FRAME TO SUPPORT M6
68
HOSE ENGINE BREATHING 8X15X2550MM, TO BE ADAPTED DURING ASSEMBLY
77
INSULATING HOSE16X1 MM, ORDER BY THE METER
80
HOSE CLAMP LINE MOUNTING
80
CLAMP , Replaced By: A0059970190
80
CLAMP , Replaced By: A1409950036
86
RUBBER RING
89
BRACKET DE-AERATION LINE TO 124 505 03 55 / 04 55
92
BRACKET , Replaced By: A0009955244
92
CLAMP
95
TANK OVERFLOW
98
HOSE FROM FEED LINE TO FILTER 240 MM
104
GROMMET MAIN CABLE HARNESS THRU WINDOW SILL 36X25 MM
107
NUT , Replaced By: N304032008006
107
NUT
110
WASHER , Replaced By: N000125008443
113
COMBINATION BOLT. TAPPING SCREW , Replaced By: N000000000548
113
TAPPING SCREW PROTECTIVE GRILLE 4.8X16 MM
116
LOOM TIE TO MOUNT PLASTIC PIPING
116
LOOM TIE , Replaced By: A0019974390
