Поз.
Артикул
Описание
5
TANK ORTHOPAEDIC BACKREST
8
SHEET METAL SCREW
11
PUMP INFRARED REMOTE CONTROL & ORTHOPAEDIC FRONT BACKREST
12
CLAMP
13
DISTRIBUTOR WITH 11 CONNECTIONS
14
PLUG BLIND PLUG,FOR FREE CONNECTIONS
15
RING
16
WASHER
17
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
18
LINE CLAMP-ON TYPE ON ONE SIDE 600 MM
19
LINE CLAMP-ON TYPE ON BOTH SIDES 900 MM
20
PLUG VACUUM ELEMENT AT FILLER NECK FLAP,F 158288
21
HOSE *** 30 MM
22
DISTRIBUTOR HEATING AND FUEL CONSUMPTION INDICATOR
23
DISTRIBUTOR MAIN FLOOR,RIGHT
26
VALVE
27
VALVE MULTI-CONTOUR BACKREST, FRONT SEAT,C 029823
29
HOUSING CONTROL VALVE,C 029823
29
HOUSING CONTROL VALVE
30
TAPPING SCREW CONTROL UNIT TO FIRE WALL
30
SHEET METAL SCREW BRACKET TO PROTECTIVE GRILL
32
BRACKET RIGHT
32
BRACKET LEFT,C 029823
32
BRACKET LEFT
32
BRACKET RIGHT,C 029823
35
RIVET
