Mercedes N000125006421 - КРЕПЕЖ

300 TE 4 MATIC JAPAN TO 09/89 124.290

62 FRONT PANEL - 001 INSTRUMENT PANEL + HOUSING WITH TRAY, SPECIAL VERSION IL.3

Поз.
Артикул
Описание
53
A1244662481
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
64
A1244601624
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A1249976382
68
A2019970382
HOSE RADIATOR, ORDER BY THE METER
71
A1249975382
HOSE (PROTECTIVE HOSE), ORDER BY THE METER
80
N916033015101
CLAMP , Replaced By: A0059972790
80
A0059972790
HOSE CLAMP FUEL LINE TO SENDER UNIT
83
A2014660182
RUBBER RING
89
A1239950265
CLAMP6/14-15 MM
92
A6171870090
CLAMP , Replaced By: A0005465143
95
A1244601324
LINE COOLING PIPE
101
N007976005203
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
104
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
104
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
107
A1244602624
LINE RETURN
