Поз.
Артикул
Описание
50
HOSE BETWEEN HEAT EXCHANGER AND WATER VALVE,LEFT
53
HOSE BETWEEN HEAT EXCHANGER AND WATER VALVE ,RIGHT
74
GROMMET FEED LINE TO FIRE WALL,F 016102
77
PIPE LINE RETURN FROM WATER VALVE TO ENGINE, 021 003042 022,023 010000
77
PIPE LINE RETURN, BETWEEN DOUBLE CONTROL VALVE HOSE & ENGINE
80
SCREW , Replaced By: A0009843429
83
WASHER , Replaced By: N000125008443
85
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
89
HOSE , Replaced By: A1268301196
89
HOSE CONDENSED WATER DRAIN,LEFT
92
HOSE CONDENSED WATER DRAIN,RIGHT
95
CLAMPING RING CONDENSED WATER DRAIN HOSE, ONLY USED WITH AIR CONDITIONING AUTOMATICS AND TEMPMATIK
98
CLAMP PRESSURE REGULATOR
98
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
101
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
101
CLAMP , Replaced By: N000000000667
104
CLAMP , Replaced By: A0059970190
104
HOSE CLAMP LINE MOUNTING
158
COVERING ENGINE,RIGHT,FOR RETURN LINE
162
CLAMP AT TUNNEL
162
CLAMP , Replaced By: A1169950001
164
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
