Поз.
Артикул
Описание
5
CHANGE-OVER VALVE CHANGE-OVER VALVE
5
VALVE. CHANGE-OVER VALVE , Replaced By: A0008000478
8
BRACKET AIR CONDITIONER CASE TO PARTITION PANEL
8
BRACKET AIR CONDITIONER CASE TO PARTITION PANEL
11
SHEET METAL SCREW , Replaced By: N007981003214
14
SHEET METAL SCREW , Replaced By: N000000000453
14
SHEET METAL SCREW MODULE TO HOUSING
17
VALVE IN ENGINE COMPARTMENT,LEFT, FOR COOLING SYSTEM & CENTRAL LOCKING MECHANISM
17
VALVE
20
DISTRIBUTOR CHANGE-OVER VALVE
23
DISTRIBUTOR CHANGE-OVER VALVE
26
DISTRIBUTOR CHANGE-OVER VALVE
29
HOSE DARK RED/GREEN, ORDER BY THE METER
32
HOSE RED/WHITE, ORDER BY THE METER
35
HOSE RED/YELLOW, ORDER BY THE METER
38
HOSE MEDIUM GREEN, ORDER BY THE METER
41
HOSE *** 30 MM
44
HOSE FROM NO.5 CHANGE-OVER VALVE TO MAIN AIR FLAP VACUUM ELEMENT 250 MM
47
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
50
HOSE FROM NO.3 CHANGE-OVER VALVE TO VACUUM DISTRIBUTOR 270 MM
53
HOSE , ORDER BY THE METER
53
HOSE , Replaced By: A0009974152
56
BRANCH-OFF FITTING
59
THROTTLE , Replaced By: A1268050175
59
THROTTLE , Replaced By: A2018050075
62
GROMMET CENTRAL NOZZLE VACUUM ELEMENT
62
GROMMET LEGROOM VACUUM ELEMENT
