Поз.
Артикул
Описание
5
CABLE HARNESS TAIL LAMP CABLE HARNESS, UP TO END OF MODEL YEAR '87
5
CABLE HARNESS TAIL LAMP CABLE HARNESS, FROM MODEL YEAR '88 UP TO END OF MODEL YEAR '90
5
CABLE HARNESS TAIL LAMP CABLE HARNESS, FROM MODEL YEAR '91 FROM IDENT NO.: (A 572098,CODE 757) ON FIVE-POLE CONNECTOR USED FOR CONNECTION OF BURGLARY ALARM SYSTEM TO RADIO SET, CUT OFF BROWN LEAD FROM CONTACT BUSHING "4" TO VEHICLE GROUND
7
PIN BUSHING HOUSING ELECTRIC WINDOW REGULATOR SWITCH VORN
8
PIN BUSHING HOUSING LAMP CONTROL
9
PIN BUSHING HOUSING , Replaced By: A0195452928, +001A0195453128
9
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
10
COVERTO 019 545 29 28
11
PIN BUSHING HOUSING 4-POLE
11
PIN BUSHING HOUSING MIRROR ADJUSTMENT SWITCH, 6-POLE
12
COVERTO 010 545 11 28
13
PIN BUSHING HOUSING RADIO PLUG-CONNECTION
14
ROUND PIN BUSHING2.5 MM2
17
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
17
PLUG TRIPLE
21
PIN BUSHING HOUSING TELL-TALE LAMP ASD
22
PIN BUSHING HOUSINGTO 000 821 26 26
22
PIN BUSHING HOUSING WINDOW REGULATOR SWITCH
23
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
26
COVERTO 006 545 81 28
29
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
32
PLUG SOCKET VACUUM PUMP
35
ROUND PIN BUSHING2,5 MM
38
PLUG HOUSING TEST INSTRUMENT CONNECTION, 12-POLE
38
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
41
COVERTO 009 545 54 28
44
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
47
CONNECTOR SWITCH
50
COVERTO 009 545 88 28
53
ROUND PIN BUSHING4 MM2
56
PLUG ADDITIONAL STOP LIGHT
59
CONTACT SPRINGTO 014 545 99 28
62
PIN BUSHING RADIO SET
62
CABLE SHOE. PIN BUSHING PRESSURE SWITCH
65
INSULATING SLEEVETO 000 546 43 40
68
PLUG HOUSING UNIPOLAR
71
SPRINGTO 002 545 92 26
74
PLUG HOUSING UNIPOLAR
77
FLAT PIN BUSHING0.5-1.0 MM2
80
INSULATING SLEEVE. PLUG HOUSING DOOR CONTACT SWITCH
83
GROMMET
83
GROMMET , Replaced By: A1079974081
86
CLIP TAIL LAMP CABLE HARNESS TO REAR LID
89
CLIP VACUUM LINE TO FLOOR,LEFT & RIGHT FRONT PANEL PILLARS
92
SCREW TAIL LAMP GROUND CABLE TO WHEEL ARCH PANEL
95
LOCK WASHER T-FITTING TO BRACKET
98
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
101
ELECTRIC CABLE FUEL PUMP
104
GROMMET
107
GROMMET
