Поз.
Артикул
Описание
5
PITMAN ARM
8
NUT , Replaced By: N304035010001
8
NUT
11
THREADED PIN
14
NUT DRAG LINK END M 24X1.5
17
TIE ROD RIGHT
17
TIE ROD LEFT
20
BALL JOINT L.H. THREAD, 023 128307 EXCEPT FOR 127479,127481,127553,127564,127586,127637,127646,127652,127654,127657,127661,127664,127669,127671, 127673,127675,127676,127678,127684,127687,127689,127690,127692-127696,127698,127701,127702,127704, 127705,127708-127727,127729-127892,127894-128306. 033 052425 EXCEPT FOR 052340,052362,052366,052367,052373-052375,052380,052382,052383,052386-052388,052393-052398,052400- 052404,052406-052423.
20
BALL JOINT R.H. THREAD
20
BALL JOINT R.H. THREAD
20
BALL JOINT L.H. THREAD, 000,003,007,102,103,105,200 10/50,12/52 A 063107 20/60,22/62 A 072609 083,086,093,183,190,193,280,283 F 007679
23
CLAMP JOINT TO TIE ROD,063899-073467
26
SCREW , Replaced By: N304017008027
26
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
29
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
32
NUT
35
REPAIR KIT TIE ROD BOOT AND DRAG LINK BOOT,RESP., 000,003,007,102,103,105,200 10/50,12/52 A 063106 20/60,22/62 A 072608 083,086,093,183,190,193,280,283 F 007678
38
DRAG LINK
41
NUT BRACKET TO CROSS MEMBER
44
STEERING INTERMEDIATE ARM
44
INTERMEDIATE LEVER , Replaced By: A1264631210, +001N000439010202, +001N000913010117
47
NUT , Replaced By: N304035010001
47
NUT
50
THREADED PIN
53
REPAIR KIT. BUSHING , Replaced By: A1244600019
53
REPAIR KIT , Replaced By: A1264600819
53
REPAIR KIT , Replaced By: A1244600150
53
INTERMEDIATE LEVER REPAIR KIT
56
SCREW SHOCK ABSORBER TO TOP BRACKET
59
DUST CAP
62
WASHER
62
SPACER WASHER , Replaced By: A1244630077
65
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
65
NUT COMBINATION CYLINDER TO BEARING BRACKET
68
SPACER WASHER AS REQUIRED 2 MM
68
SPACER WASHER
71
SHOCK ABSORBER (STEERING SHOCK ABSORBER)
74
SCREW , Replaced By: N308676010023
74
SCREW , Replaced By: N000961010031
74
SCREW BRACKET TO CROSS MEMBER M 10X40
77
NUT , Replaced By: N910113010002
77
HEXAGON NUT
