Поз.
Артикул
Описание
5
LOCK LOWER PART,REAR LID
8
HEXAGON HEAD BOLT
8
SCREW , Replaced By: N910105006002
9
SCREW , Replaced By: N000000001933
9
SCREW FUSE BOX TO SIDE MEMBER,5 097182
10
COVERING ,A 314155
11
LOCK UPPER PART
12
LOCK UPPER PART, BURGLARY ALARM SYSTEM
14
PAD
15
PAD LOCK UPPER PART TO REAR LID
16
PLATE LOCK UPPER PART TO REAR LID
17
PLATE
20
SCREW , Replaced By: N304017006018
20
SCREW , Replaced By: N304017006020
20
SCREW COVER PLATE TO COVER PLATE M 6 X 12
20
SCREW LICENSE PLATE TO BRACKET
23
RUBBER BUFFER
26
LOCK , Replaced By: A1267503385
26
LOCK WORKSHOP VERSION,WITH KEY, WITH CODE 551 (EDW)
29
LOCK , Replaced By: A1267502385
29
LOCK , Replaced By: A1267502385
29
LOCK
32
ROUND SECTION SEAL RING LOCK TO HOUSING
35
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
35
SCREW , Replaced By: N007985005157
38
MERCEDES STAR REAR LID
47
GROMMET MERCEDES STAR TO REAR LID
50
HANDLE (GARNISH MOULDING),REAR LID,A 609425 ONLY FOR R.S.A.
53
COMBINATION BOLT
68
TYPE DESIGNATION ON REAR LID,ADHESIVE 420 SEL
