Mercedes N304017008021 - АВТОЗАПЧАСТЬ

500 SEL SONDERSCHUTZ/SPECIAL EDITION 126.037

52 UNDERSHIELDS - 001 UNDERSHIELDS USED FOR OIL PAN AND RADIATOR

Поз.
Артикул
Описание
44
A0019100586
BACKREST ADJUSTER RIGHT SEAT, LEFT
47
A1269100985
BACKREST ADJUSTER RIGHT,A 311858
47
A0019100085
BACKREST ADJUSTER , ORDER ADDITIONALLY UP TO CHASSIS,SEE FOOTN. 5 ,1 BRACKET ADJUSTER 001 910 05 86A 311857, Replaced By: A1269100985, +001A1269180125, +001N910001004107
50
A1269180227
LINK BACKREST ADJUSTER
53
N304017008021
SCREW PIPE CLAMP
53
N000933008147
SCREW , Replaced By: N304017008021
56
N000934008010
NUT , Replaced By: N304032008006
56
N304032008006
NUT
155
A2019900422
SCREW HORN TO BRACKET
158
A1269900122
SCREW BACKREST TO SEAT FRAME
161
A1268680190
CATCH BACKREST TO SEAT FRAME
