Поз.
Артикул
Описание
5
CONTROL UNIT ,F 090316, Replaced By: A0055450532, +001A0055454432
11
BRACKET CONTROL UNIT
11
BRACKET , Replaced By: A1265455840
14
SHEET METAL SCREW , Replaced By: N000000000459
14
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
17
SCREW CAB FLOOR COVERING M 6X25
23
CLIP CONTROL UNIT TO BRACKET
26
CLIP CONTROL UNIT TO BRACKET
29
CONTROL UNIT ACTUATOR
32
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
35
COVERTO 006 545 81 28
38
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
41
LEVER
44
NUT
47
LOCK
65
SCREW 3/2-WAY VALVE TO BRACKET
71
NUT BALL PIVOT TO LEVER
77
GROMMET FINAL CONTROL ELEMENT TO BRACKET
83
SPACER ACTUATOR TO BRACKET, Replaced By: A0009923760
89
WASHER ACTUATOR TO BRACKET
95
SOCKET-TERMINAL STRIP BIPOLAR
98
SCREW ELECTRIC CABLE TO FUSE BOX
101
LOCK WASHER T-FITTING TO BRACKET
104
CABLE HARNESS SPEEDOMETER CONNECTION ADAPTER USED FOR SPEED SIGNAL
107
ELECTRIC CABLE , Replaced By: A1265409535
107
ELECTRIC CABLE TEMPOMAT (CRUISE CONTROL),A 288303 ALSO INSTALLED ON: A 288016,A 288069,A 288125,A 288149,A 288182,A 288188,A 288219,A 288242,A 288254,A 288261,A 288270,A 288281.
110
PIN BUSHING HOUSING 4-POLE
113
COVER
116
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
119
COVERTO 006 545 81 28
122
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
125
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
128
COVERTO 019 545 29 28
131
ROUND PIN BUSHING2.5 MM2
134
GROMMET
149
ROD
