Поз.
Артикул
Описание
8
RESERVOIR WINDSHIELD WASHER HEATED,A 363211
8
RESERVOIR , Replaced By: A1268690820
14
COVERING , Replaced By: A1268690608
14
COVERING WINDSHIELD WASHER RESERVOIR,F 084208
17
SEAL ,A 363211
20
GROMMET ,F 084208
23
FILLER CAP
26
SEAL RING ,F 084208
29
RUBBER BUFFER BRACKET AT BOX
29
GROMMET , Replaced By: A1159870840
32
HOLDER
35
HEATER UNIT ,A 428785, Replaced By: A1268301261, +001A1268690820
35
HEATER UNIT , Replaced By: A1268301861
35
HEATER UNIT HEATED WINDSHIELD WASHER RESERVOIR,A 428786
38
VALVE , F 184896
41
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
41
SEAL RING , Replaced By: A1409970645
44
SCREW , F 184896
47
TOOTHED WASHER , F 184896
50
NUT , F 184896
53
CONNECTION , F 184896
56
HOSE40 MM
71
PUMP HEADLAMP WIPER/WASHER, AT WINDSHIELD WASHER RESERVOIR, FROM CHASSIS: 107.022 005201, ALSO INSTALLED ON: 005190-005192,005194-005199 107.023 012497 107.024 021804, ALSO INSTALLED ON: 021794,021802 107.025,026,045,046 000001 107.042 004222, ALSO INSTALLED ON: 004213,004215-004218,004220 107.043 013577 107.044 047068, ALSO INSTALLED ON: 047057,047061,047062,047064-047066 UP TO CHASSIS SEE SA 55873/12
71
PUMP , Replaced By: A1248690621
71
PUMP , Replaced By: A1248690521
71
PUMP , Replaced By: A1248690421
71
PUMP , Replaced By: A1248690621
71
PUMP , Replaced By: A2028690021
71
PUMP , Replaced By: A2028690021
71
PUMP , Replaced By: A2028690021
74
GROMMET CENTRIFUGAL PUMP CONNECTION
77
CHECK VALVE (CHECK VALVE),WINDSHIELD WASHER, 000 159697 003 078977 007 064070 083 004734 086 003596 093 004546 102,103 149491 105 164442 183 008116 190 011709
77
VALVE (CHECK VALVE),WINDSHIELD WASHER
80
HEATING ELEMENT , Replaced By: A0008206198
80
HEATING ELEMENT ,F 084208
83
COVERING CHECK VALVE TO ENGINE HOOD,REAR,A 363211
101
HOSE FROM PUMP TO CHECK VALVE,A 363211
113
HOSE
116
HOSE FROM CHECK VALVE TO LEFT NOZZLE,A 363211
116
HOSE FROM CHECK VALVE TO LEFT NOZZLE,A 363211, Replaced By: A1268600592
119
CLAMP
119
CLAMP
122
HOSE FROM CHECK VALVE TO RIGHT NOZZLE,A 363211
122
HOSE FROM CHECK VALVE TO RIGHT NOZZLE,A 363211, Replaced By: A1268600692
125
CLAMP
125
CLAMP
125
LOOM TIE
128
CLAMP
128
CLAMP , Replaced By: A0009955244
131
CLIP , Replaced By: A0059889178
131
CLIP CABLE HARNESS TO SIDE PART
137
NOZZLE ENGINE HOOD, LEFT,A 363211
137
NOZZLE ENGINE HOOD,RIGHT,A 363211
140
COVERING ENGINE HOOD, LEFT,A 363211
140
COVERING ENGINE HOOD,RIGHT,A 363211
143
CABLE STRAP LINE MOUNTING 260X3.3MM
143
CLAMP , Replaced By: A0059976290
149
PLATE ,F 084208
