Поз.
Артикул
Описание
5
PANELLINGB6 6 02 0691, TO BE ADAPTED TO VEHICLE PRIOR TO PAINTING FOR COLOR NUMBERS AND PAINT CODES USED FOR OUTSIDE PARTS,SEE FOOTNOTE 901 TO BE PAINTED PRIOR TO INSTALLATION F 125157 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE FROM F 125158 WITH CODE 805
5
REAR BUMPER FACE BAR , F 125157 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE FROM F 125158 WITH CODE 805 TO BE PAINTED PRIOR TO INSTALLATION FOR COLOR NUMBERS AND PAINT CODES USED FOR OUTSIDE PARTS,SEE FOOTNOTE 901
14
SCREW LEVER TO SHAFT
17
NUT BRACKET TO ANTENNA, ONLY USED WITH REAR END MOUNTINGA 001878
20
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
23
SHEET METAL SCREW MODULE TO HOUSING
26
GUIDE ON REAR END FLOOR,LATERAL LEFT AND RIGHT
29
WASHER REAR LATERAL GUIDE TO REAR END FLOOR,F 021177
32
WASHER
35
NUT HEATING PIPE TO BRACKET
38
NUT BUMPER TO TAIL CENTRAL PIECE
