Поз.
Артикул
Описание
5
RESERVOIR SELF-LEVELLING DEVICE OIL RESERVOIR, F 125157 EXCEPT FOR WITH CODE 806
5
RESERVOIR SELF-LEVELLING DEVICE OIL RESERVOIR, F 125158 ALSO INSTALLED ON WITH CODE 806
8
COVER
11
COVER SELF-LEVELLING DEVICE OIL RESERVOIR
14
FILTER
17
SPACER
20
SEAL RING
23
NUT
26
HOUSING OIL DIPSTICK
29
SENDER UNIT OIL LEVEL SENDER UNIT, F 125157 EXCEPT FOR WITH CODE 806
32
GROMMET
32
GROMMET , Replaced By: A1409974281
32
GROMMET , Replaced By: A1269974881
35
MOUNTING BOW , F 125157 EXCEPT FOR WITH CODE 806
38
GROMMET UNDER OIL RESERVOIR, TO BE ADAPTED DURING ASSEMBLY
41
VALVE SELF-LEVELLING DEVICE CONTROL VALVE, UP TO MODEL YEAR '95
56
SEAL RING , F 125157 EXCEPT FOR WITH CODE 806
68
SEAL RING , F 125157 EXCEPT FOR WITH CODE 806
71
DISTRIBUTOR SELF-LEVELLING DEVICE CONTROL VALVE, UP TO MODEL YEAR '95
74
SCREW OIL LINES TO ENGINE,001498
77
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
77
NUT , Replaced By: N913023006001
80
VALVE SELF-LEVELLING DEVICE CONTROL VALVE, F 125158 ALSO INSTALLED ON WITH CODE 806
83
VALVE , F 125158 ALSO INSTALLED ON WITH CODE 806
83
VALVE , Replaced By: A1293271925
86
BRACKET , F 125158 ALSO INSTALLED ON WITH CODE 806
89
SCREW COVER PLATE TO COVER PLATE M 6 X 10
92
AIR CELL (SPRING LOAD ACCUMULATOR)
95
FITTING WATER SEPARATOR
98
SEAL RINGTO 000 553 03 05,000 553 18 05,
104
BRACKET LEFT FRONT DAMPING VALVE
104
BRACKET RIGHT FRONT DAMPING VALVE
107
NUT , Replaced By: N913004008001
110
SCREW COVER TO SPACER RING
113
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
113
NUT , Replaced By: N913023006001
119
VALVE ,F086564, Replaced By: A1293271425, +001A1293208172, +001A1293208272, +001A1404405934
119
VALVE (DAMPING VALVE),FRONT, F 125157 EXCEPT FOR WITH CODE 806
119
VALVE (DAMPING VALVE),FRONT, F 125158 ALSO INSTALLED ON WITH CODE 806
122
SCREW VALVE TO BRACKET M 8X55
122
SCREW , Replaced By: N304017008043
125
WASHER , Replaced By: N000125008443
128
NUT RETAINER MOUNTING FRAME TO SUPPORT,V 202043
