Поз.
Артикул
Описание
5
CABLE HARNESS FOLDING TOP,FRONT,F 097567
10
PIN BUSHING HOUSING TELL-TALE LAMP ASD
15
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
20
PLUG HOUSINGADS-ASD
25
PLUG PIN
30
GROMMET BREATHER LINE
35
CONTROL UNIT , F 125158 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO F 125157 WITH CODE 806 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
40
NUT , Replaced By: N913023006001
40
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
45
COVERING FOLDING TOP CONTROL UNIT
50
CABLE CONDUIT FOLDING TOP LOCK,FRONT RIGHT
50
CABLE CONDUIT FOLDING TOP LOCK,FRONT LEFT
55
SWITCH FOLDING TOP LOCK,REAR LEFT
55
SWITCH FOLDING TOP LOCK,CENTRAL RIGHT,F 097567
55
SWITCH FOLDING TOP LOCK,REAR RIGHT,F 097567
60
PLUG HOUSING ENGINE CABLE HARNESS PLUG-CONNECTION
65
PLUGTO 012 545 89 28, UP TO END OF MODEL YEAR '85
70
BRACKET
75
SWITCH ON FRONT PANEL,TO FOLDING TOP CASE COVER,LEFT,F 169830
80
PLUG INTERMEDIATE CONNECTOR,STARTING LOCK
85
PLUG PIN0.5-2.0 MM2
90
NUT CONTROL UNIT TO BRACKET
95
SWITCH FOLDING TOP CASE COVER,RIGHT
100
SCREW SWITCH TO REAR PANEL
105
SWITCH ROOF RAIL,FRONT,F 097567
110
PLUG INTERMEDIATE CONNECTOR,STARTING LOCK
115
PLUG PIN0.5-2.0 MM2
120
BRACKET ROOF RAIL,FRONT,F 097567
125
MAGNET ON FOLDING TOP FRONT RAIL,F 097567
130
SWITCH FABRIC RETAINING BOW,LEFT
135
PLUG HOUSING
140
PLUG PIN
145
SCREW
