Mercedes N304017008021 - АВТОЗАПЧАСТЬ

600 SL / SL 600 TO 06/98 129.076

32 SPRINGS,SUSPENSION AND HYDRAULICS - 090 FRONT TORSION BAR & HEIGHT CONTROL VALVE USED WITH SELF-LEVELLING DEVICE

Поз.
Артикул
Описание
5
A1295241330
PANELLING ENGINE COMPARTMENT
10
A0019949845
LOCK. CLIP-TYPE NUT
15
A2019900536
SCREW. SHEET METAL SCREW
20
A1295241030
PANELLING SIDE PART,LEFT, TO BE ADAPTED DURING ASSEMBLY
25
N914128004200
SHEET METAL SCREW
30
A2019901136
SCREW
35
A1295241240
BRACKET SIDE PART,LEFT
40
N914128004200
SHEET METAL SCREW
45
A1295240247
STRUT
50
A1295240347
STRUT
55
A1295240447
STRUT
60
A1295240088
COVER PLATE
65
A0019902512
SCREW
70
A1295240176
WASHER
75
A1039880111
BUFFER
80
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
80
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
85
N000934006007
NUT BALL PIVOT TO LEVER
90
A1295200542
PROTECTIVE PLATE OIL PAN UNDERSHIELD
95
N304017008021
SCREW PIPE CLAMP
100
N913023008003
NUT HORN TO BRACKET M8
105
A2019900204
SCREW STEERING COLUMN JACKET TUBE TO BODY
110
A2019900991
NUT RETAINER AT SUPPORT
110
A0049941845
SPRING-THREAD NUT PROTECTIVE PLATE
