Поз.
Артикул
Описание
5
RESERVOIR PANE WASHER
5
RESERVOIR , Replaced By: A1408600260
8
SCREW , Replaced By: N304017006016
8
SCREW PUMP TO BRACKET
11
RIVET RESERVOIR TO BRACKET 4X0.5X8
14
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
14
WASHER COMPRESSED AIR LINE TO BRACKET
20
NUT HEATING PIPE TO BRACKET
20
NUT PUMP TO BRACKET
20
NUT , Replaced By: N913004006001
23
SEAL
26
COVERING PANE WASHER
29
GROMMET FILLER NECK
32
FILLER NECK
35
COVERING FILLER NECK
38
COMBINATION BOLT
41
LOCK CONDENSER TO INTERIOR PLATE,LEFT OUTSIDE
41
LOCK PROTECTIVE GRILLE
44
HEATER UNIT HEATED WINDSHIELD WASHER RESERVOIR
47
VALVE , F 184896
50
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
53
SCREW , F 184896
56
TOOTHED WASHER , F 184896
59
NUT , F 184896
62
CONNECTION , F 184896
65
GROMMET ,F 084208
68
EXPANSION PLUG WHEELHOUSES, REAR FENDERS
71
NUT WINDOW REGULATOR TO REAR DOOR
74
INDICATOR WINDSHIELD WASHER WATER LEVEL, A 204157
77
CLIP WINDSHIELD WASHER WATER LEVEL, A 204157
80
CLIP WINDSHIELD WASHER WATER LEVEL, A 204157
83
SENDER UNIT WINDSHIELD WASHER WATER LEVEL, F 140422 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO F 140421 WITH CODE 807
83
SENDER UNIT WINDSHIELD WASHER WATER LEVEL,F 081485
83
SENDER UNIT , Replaced By: A1405400017
86
GROMMET , Replaced By: A1409974281
86
GROMMET
89
PUMP PANE WASHER, F 140422 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO F 140421 WITH CODE 807
89
PUMP PANE WASHER, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
89
PUMP PANE WASHER, A 328810 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM A 328811 WITH CODE 806
89
PUMP PANE WASHER, F 140422 EXCEPT CODE 806 ALSO INSTALLED IN VEHICLE TO F 140421 WITH CODE 807
89
PUMP PANE WASHER
92
PUMP HEADLAMP WIPER/WASHER, AT WINDSHIELD WASHER RESERVOIR, FROM CHASSIS: 107.022 005201, ALSO INSTALLED ON: 005190-005192,005194-005199 107.023 012497 107.024 021804, ALSO INSTALLED ON: 021794,021802 107.025,026,045,046 000001 107.042 004222, ALSO INSTALLED ON: 004213,004215-004218,004220 107.043 013577 107.044 047068, ALSO INSTALLED ON: 047057,047061,047062,047064-047066 UP TO CHASSIS SEE SA 55873/12
92
PUMP , Replaced By: A1248690621
92
PUMP , Replaced By: A2028690021
92
PUMP , Replaced By: A2028690021
92
PUMP , Replaced By: A2028690021
95
GROMMET CENTRIFUGAL PUMP CONNECTION
98
EXPANSION PLUG TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
98
RUBBER BUFFER TO PLUG THE FREE CONNECTIONS
101
HOSE , Replaced By: A1408601092
101
HOSE
101
HOSE
104
HOSE FROM RIGHT NOZZLE TO CHECK VALVE 900 MM
107
CONNECTOR
110
CONNECTOR AT LEFT AND RIGHT NOZZLES
110
CONNECTOR , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS A 131644 F 047890, Replaced By: A1248690024
113
CLAMP
119
CHECK VALVE (CHECK VALVE),WINDSHIELD WASHER, 000 159697 003 078977 007 064070 083 004734 086 003596 093 004546 102,103 149491 105 164442 183 008116 190 011709
122
HOSE CHECK VALVE
125
CLAMP
125
CLAMP
125
CLAMP , Replaced By: A0009956044
125
CLAMP , Replaced By: A0009955244
125
CLAMP BOWDEN CABLE TO CAB
128
NOZZLE ENGINE HOOD
128
NOZZLE , Replaced By: A1408601047
128
NOZZLE , Replaced By: A2108601847
131
PLATE ,F 084208
