Поз.
Артикул
Описание
5
HEATER UNIT RANGE OF DELIVERY
8
PIPE
11
SEAL RING
14
MUFFLER INTAKE MUFFLER
17
BURNER INSET
17
COVER , Replaced By: A0005000053
20
LOCKING CAP (FLAME DETECTION PHOTOCELL)
23
SENDER UNIT TEMPERATURE SENSOR
26
SEAL RING ,5 385342
29
FUSE
32
SEAL RING ,5 385342
35
RESISTOR
38
BLOWER
41
SEAL RING
44
CLAMP HOSE 70-90X13 MM
44
LOOM TIE , Replaced By: N916017070000
44
CLAMP , Replaced By: N000000000674
47
PLUG (PLUG CONNECTION)
50
PLUGTO 012 545 89 28, UP TO END OF MODEL YEAR '85
53
LOCKING CAP
59
RUBBER MOUNTING HEATER UNIT TO WHEEL ARCH, A 209749 F 108104
62
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
62
NUT , Replaced By: N913023006001
62
NUT , Replaced By: N910112006001
65
SCREW PROTECTIVE PLATE, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
65
SCREW , 183 003776 190 004444
68
BRACKET
71
BRACKET
74
BRACKET
77
HOSE
80
CLAMP LINE MOUNTING
83
BRACKETAN FAHRSCHEMELKONSOLE RECHTS,A 207840
86
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
86
NUT , Replaced By: N913023006001
86
NUT , Replaced By: N910112006001
221
BRACKET EXHAUST MUFFLER
224
SCREW , 183 003776 190 004444
227
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
227
NUT , Replaced By: N913023006001
227
NUT , Replaced By: N910112006001
230
MUFFLER EXHAUST MUFFLER
233
HOSE EXHAUST PIPE TO MUFFLER 1380 MM, ORDER BY THE METER
236
CLAMP EXHAUST PIPE
239
FRONT EXHAUST PIPE
242
BRACKET
245
RUBBER MOUNTING BETWEEN HEATER UNIT AND EXHAUST MUFFLER,B 377200
248
SCREW BRACKET TO FIRE WALL
248
SHEET METAL SCREW , Replaced By: N000000000542
251
CLAMP , UP TO CHASSIS107.024 012078 107.044 029875
252
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
252
NUT , Replaced By: N913023006001
252
NUT , Replaced By: N910112006001
254
SCREW PROTECTIVE PLATE, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
254
SCREW , 183 003776 190 004444
