Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLY LESS STEERING COUPLING
5
STEERING BOX ASSEMBLY WITH PITMAN ARM,A 166260 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
STEERING BOX ASSEMBLY , Replaced By: A1404605601
14
SEAL RING CONTROL VALVE
17
SCREW CLAMP TO EXHAUST PIPE
17
SCREW
20
HEXAGON NUT
20
NUT STRAP TO BRACKET
23
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
26
SEAL RING
29
SEAL RING
32
LOCK
35
SEAL RING
38
SEAL RING FLANGE
41
SEAL RING
44
THREADED INSERT
47
WASHER
56
SEAL RING , 023 10/50,12/52 056284 023 20/60,22/62 057848 033 10/50,12/52 027436 033 20/60,22/62 028023 123 10/50,12/52 029863 123 20/60,12/52 041002 130 10/50,12/52 051238 130 20/60,22/62 052678
59
SEAL RING , 023 10/50,12/52 056284 023 20/60,22/62 057848 033 10/50,12/52 027436 033 20/60,22/62 028023 123 10/50,12/52 029863 123 20/60,12/52 041002 130 10/50,12/52 051238 130 20/60,22/62 052678
62
LOCK , 023 10/50,12/52 056283 023 20/60,22/62 057847 033 10/50,12/52 027435 033 20/60,22/62 028022 123 10/50,12/52 029862 123 20/60,12/52 041001 130 10/50,12/52 051237 130 20/60,22/62 052677
65
SCREW FEED LINE AND RETURN LINE
68
GASKET BEARING COVER TO STEERING BOX
68
GASKET BEARING COVER TO STEERING BOX
68
GASKET BEARING COVER TO STEERING BOX
74
SCREW. CAP BOLT COVER TO CASE M8X25
77
WASHER BRACKET TO CROSS MEMBER
80
SCREW ADJUSTING SCREW
83
LOCK ADJUSTING SCREW
86
NUT , Replaced By: A0009904050
86
NUT
89
THRUST WASHER2.70 MM
89
THRUST WASHER2.80 MM, TO BE ADAPTED DURING ASSEMBLY
89
THRUST WASHER2.85M
89
THRUST WASHER2.80 MM, Replaced By: A1074620262
89
THRUST WASHER3.00 MM
89
THRUST WASHER3.10 MM
89
THRUST WASHER2.65 MM
89
THRUST WASHER3.05 MM
89
THRUST WASHER2.95 MM
89
THRUST WASHER2.75 MM
92
LOCK REVERSE IDLER SHAFT
95
SCREW PLUG
98
THRUST WASHER SHOCK ABSORBER TO TOP BRACKET
101
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
104
SEAL RING STEERING WORM SECTOR SHAFT
107
SEAL RING
116
SEAL RING STEERING WORM SECTOR SHAFT
119
SEAL RING STEERING WORM SECTOR SHAFT
125
VALVE , Replaced By: A1404660191
125
VALVE
128
SEALING RING. SEAL RING OIL DRAIN
131
STEERING BOX COVER
131
STEERING BOX COVER
134
SEAL RING VALVE
137
SCREW
140
PIN
143
SPRING , 1F 058035 2F 052098
146
SCREW PLUG ADJUSTER
155
STEERING COUPLING , LESS PARAMETRIC STEERING 1 A 033659 2 A 031993 WITH PARAMETRIC STEERING A 033950A 166259
156
STEERING COUPLING ,A 166260, Replaced By: A2104600110
156
STEERING COUPLING ,A 166260, Replaced By: A2104600210
156
STEERING COUPLING ,A 166260
161
SCREW STEERING COUPLING TO STEERING SHAFT, LESS PARAMETRIC STEERING 1 A 033659 2 A 031993 WITH PARAMETRIC STEERING A 033950A 166259
161
SCREW , Replaced By: A2029902101
161
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
161
SCREW
162
SCREW , Replaced By: A2109900604
162
SCREW STEERING COUPLING TO STEERING GEAR,A 166260
163
NUT STEERING COUPLING TO STEERING GEAR,A 166260
164
SCREW , Replaced By: A1409906101
164
SCREW STEERING TO FRAME
167
GASKET KIT
