Поз.
Артикул
Описание
5
FUEL PUMP , ONLY FOR R.S.A.
5
FUEL PUMP , Replaced By: A0030915301
6
AUXILIARY PUMP ,C 227245, J 081289 ONLY FOR R.S.A.
6
FUEL PUMP
8
VALVE
11
SEAL RING FITTING TO AXLE HOUSING
14
INSULATION
17
SPACER TUBE , F 282121
18
HOSE FROM FEED LINE TO FILTER 240 MM
18
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
18
HOSE FUEL LINE TO TANK 13.5 X 7.5 MM, ORDER BY THE METER
19
CLAMP LINE CONNECTION
20
FUEL FILTER , NOT FOR AUSTRALIA
20
FUEL FILTER , Replaced By: A0024774501
20
FUEL FILTER , NORMAL COURSE OF REPAIR, Replaced By: A0024774401
20
FUEL FILTER , ONLY FOR R.S.A.
20
FUEL FILTER , Replaced By: A0024774501
21
FUEL FILTER ,C 226336
21
FUEL FILTER ,C 226336
23
SPACER TUBETO 002 477 06 01/19 01/2701/2801/4501
23
INSULATION
26
BRACKET PUMP,FILTER & FUEL ACCUMULATOR,F 807581
26
BRACKET , Replaced By: A2014785140
29
BRACKET BOTTOM,C 227244 , J 081288
32
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
35
BRACKET FUEL HOSE
38
NUT TACHOGRAPH TO BRACKET
41
BRACKET SENSOR LINE MOUNTING
44
SCREW BOOT
47
RUBBER RING
47
RUBBER RING , ONLY FOR R.S.A.
48
BRACKET FUEL PUMP TO FILTER,C 226336
49
SCREW
50
BRACKET FLOOR
53
BRACKET FLOOR
56
NUT COVERING TO CAB FIRE WALL
59
LINE
62
NUT
65
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
68
HOLLOW SCREW HEATING CONNECTION
71
LINE
74
CLAMP FROM VENT PIPE TO FILLER NECK
77
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
77
NUT TACHOGRAPH TO BRACKET
80
TOOTHED WASHER BACK-UP LAMP TO BRACKET
80
TOOTHED WASHER COVER TO COVERING,K 093739
