Поз.
Артикул
Описание
5
RAIL REAR DOOR,BOTTOM RIGHT
5
RAIL REAR DOOR,BOTTOM LEFT
8
RAIL REAR DOOR,TOP RIGHT
8
RAIL REAR DOOR,TOP LEFT
11
SHEET METAL SCREW
14
PLATE RAIL TO ROOF COVERING
14
PLATE RAIL TO REAR DOOR COVERING
17
WASHER BRACKET TO SUPPORT
20
NUT ANTENNA COMBINER TO COVERING
23
CURTAIN LEFT,REAR DOOR
23
CURTAIN RICHT,REAR DOOR
26
RING
29
HOOK
32
SLIDE
35
CLIP FOR DETENT
38
CLIP FOR DETENT
41
STRAP CURTAIN
44
CURTAIN REAR WINDOW, LEFT,A 404185 IF RETROFITTING REAR WINDOW CURTAIN,PARCEL SHELF WITH CODE 296 MUST BE ORDERED TOGETHER WITH PARTS SCOPE 68/605
44
CURTAIN REAR WINDOW, LEFT,A 404184 IF RETROFITTING REAR WINDOW CURTAIN,PARCEL SHELF WITH CODE 296 MUST BE ORDERED TOGETHER WITH PARTS SCOPE 68/605
47
CURTAIN REAR WINDOW,RIGHT,A 404185 IF RETROFITTING REAR WINDOW CURTAIN,PARCEL SHELF WITH CODE 296 MUST BE ORDERED TOGETHER WITH PARTS SCOPE 68/605
47
CURTAIN REAR WINDOW,RIGHT,A 404184 IF RETROFITTING REAR WINDOW CURTAIN,PARCEL SHELF WITH CODE 296 MUST BE ORDERED TOGETHER WITH PARTS SCOPE 68/605
50
RING
53
HOOK
56
RING
59
RAIL AT HAT TRAY
62
PLATE RAIL TO ROOF COVERING
65
WASHER BRACKET TO SUPPORT
68
NUT ANTENNA COMBINER TO COVERING
71
CLIP FOR DETENT
74
RING
77
BRACKET GUIDE TUBE
80
TAKE-UP DEVICE ENGINE
83
PLATE ENGINE
86
NUT ANTENNA COMBINER TO COVERING
89
CLAMP CHECK VALVE,K 169122
92
TUBE REAR WINDOW, LEFT
92
TUBE REAR WINDOW,RIGHT
95
CURTAIN PULL TOP
95
CURTAIN PULL BOTTOM
98
SCREW REAR ROOF RAIL
98
SHEET METAL SCREW MODULE TO HOUSING
101
RAIL REAR ROOF RAIL
104
REINFORCEMENT RAIL TO ROOF COVERING
107
BRACKET PANELLING TO ROOF REAR RAIL
110
CLIP PANELLING TO ROOF REAR RAIL
113
COVERING ,NO.7C44I NO.7C44I NO.8F54I NO.8F54I NO.8F43I NO.8F43I NO.8F43I NO.7C44I
116
ADHESIVE TAPE BETWEEN OUTSIDE ROOF RAIL AND ROOF 1150 MM, ORDER BY THE METER
119
RIVET APPARATUS PLATE TO INSTRUMENT PANEL
122
INTERMEDIATE PIECE C-PILLAR
125
COVERING AT BOTTOM OF REAR PILLAR PANELING
125
COVERING AT TOP OF REAR PILLAR PANELING
128
BRACKET
131
COVERING
134
REINFORCEMENT
137
COVER
140
SHEET METAL SCREW PANELLING TO INTERIOR PLATE
