Поз.
Артикул
Описание
30
BACKREST FRAME LEFT
40
BACKREST FRAME RIGHT
45
REST LEFT BACKREST
45
REST LEFT BACKREST
47
REST RIGHT BACKREST
47
REST RIGHT BACKREST
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST
70
COVER LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
COVER LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
BACKREST UPHOLSTERY LEFT REAR BACKREST
70
COVER REAR SEAT BACKREST LEFT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST
80
BACKREST UPHOLSTERY RIGHT REAR BACKREST
80
BACKREST UPHOLSTERY RIGHT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST
80
BACKREST UPHOLSTERY RIGHT REAR BACKREST
80
BACKREST UPHOLSTERY RIGHT REAR BACKREST
80
COVER RIGHT REAR BACKREST
80
BACKREST UPHOLSTERY RIGHT REAR BACKREST
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
80
COVER REAR SEAT BACKREST RIGHT REAR BACKREST, 9E43 231A QFT164A2611 BLACK
90
AIR BAG TO BACKREST FRAME
90
AIR BAG TO BACKREST FRAME
100
RIVET
110
BACKREST ADJUSTER LEFT
210
GUIDE LEFT,HEADREST
220
GUIDE HEAD RESTRAINT SEAT RIGHT, RIGHT
230
UNLOCKING LEFT
230
UNLOCKING RIGHT
235
BOLT UNLOCKING MECHANISM TO FRAME M8X50
240
BOWDEN CABLE BACKREST LOCKING MECHANISM,LEFT
250
BRACKET LEFT BACKREST
255
BOLT. SCREW CAN NEUTRAL POINT ON EQUIPMENT PLATE M5 X 14
260
COVER RIGHT BACKREST, OUTER
260
COVER LEFT BACKREST, OUTER
270
HOOK REAR PANEL,TOP
280
BEARING BACKREST, RIGHT
290
COVER LEFT BACKREST, INNER
305
COVER LEFT BACKREST
310
COVER RIGHT BACKREST
330
COVER REAR PANEL, BELOW
335
COVER REAR PANEL, BELOW
340
SHACKLE BELT GUIDE, CENTER
345
HEXALOBULAR BOLT EXPANSION TANK M8X20
350
COVER BELT OUTLET,LEFT
360
COVER BELT GUIDE LEFT
370
COVER BELT GUIDE LEFT
390
COVER BELT COVERING LEFT, 9051QFT164A0410 BLACK
400
ESCUTCHEON REAR SEAT BENCH,LEFT
410
HEXALOBULAR BOLT SUPPORTING STRUT AT BRACKET AT RIGHT BOTTOM M12X1,5X30
445
BOLT BACKREST, RIGHT M10X40
450
PIN PIVOT BEARING,RIGHT
450
PIN PIVOT BEARING,LEFT
460
COVER FITTINGS TO BACKREST
470
COVER FOR "ISOFIX"
480
BEARING SUPPORT ON CUSHION FRAME
522
PLUG HOUSING SWITCH TO CLUTCH PEDAL 2-PIN JPT2.8
524
CONTACT SPRING0.5-1.0 MM2
600
BRACKET REAR SEAT BENCH,LEFT
610
BOLT. SCREW CAN NEUTRAL POINT ON EQUIPMENT PLATE M 6X15/10
690
MOUNTING BRACKET LONGITUDINAL STAPLE UPHOLSTERY, CENTER RIGHT SEAT
700
BRACKET SEAT COVER MOUNTING,LONGITUDINAL
705
MOUNTING BRACKET TRANSVERSAL TACKING, A 48000720081001809
710
CLIP SEAT COVER MOUNTING,TRANSVERSE
740
INSERT REAR BACKREST TO BACKREST FRAME, RIGHT
750
BOLT FASTENING, STRIKERS M6X13
750
SCREW BRACKET TO COVERING
760
COVER LEFT SEAT ISOFIX
770
CONSOLE LEFT BACKREST
770
CONSOLE RIGHT BACKREST
900
ARMREST FOLDING
900
ARMREST FOLDING
900
ARMREST FOLDING
900
ARMREST FOLDING
900
ARMREST
910
COVER ARMREST
920
BRACKET ARMREST ON THE RIGHT
920
BRACKET ARMREST ON THE LEFT
925
BOLT (DELIVERY LINE), FROM PUMP TO STEERING M6X16
990
REP.SET CONTACT WINDOWBAG SQUIB, REAR 2-PIN 0.5MM2,R12/22 R12/23
