Поз.
Артикул
Описание
100
SHIELDING LEFT
110
SHIELDING RIGHT, L 00123120130331 M 00123120130331 A 13822220120928803
110
SHIELDING RIGHT, A 13822220120928803
120
HEXAGON NUT W COLLAR BRACKET MOUNTING
130
BOLT LOWER SUPPORT M6X19
135
HEXAGON NUT W COLLAR BRACKET MOUNTING
140
BOLT LOWER SUPPORT M6X19
150
SCREENING PLATE FRAME-TYPE INTEGRAL SUPPORT,LEFT, L 00301720131130 M 00301720131130 A 20131110
150
SCREENING PLATE FRAME-TYPE INTEGRAL SUPPORT,RIGHT
150
SCREENING PLATE FRAME-TYPE INTEGRAL SUPPORT,LEFT, L 00301820131130 M 00301820131130 A 20131110
160
HEXAGON HEAD BOLT
170
MOUNTING CLAMP SHIELDING TO INTEGRAL CARRIER, LEFT
220
SHIELDING LEFT
220
SHIELDING LEFT, L 00123120130331 M 00123120130331 A 13822220120928803
230
HEXAGON NUT W COLLAR BRACKET MOUNTING
240
SHIELDING LEFT, L 00123120130331 M 00123120130331 A 13822220120928803
240
SHIELDING LEFT
250
HEXAGON NUT W COLLAR BRACKET MOUNTING
260
SHIELDING RIGHT
260
SHIELDING RIGHT, L 00123120130331 M 00123120130331 A 13822220120928803
270
HEXAGON NUT W COLLAR BRACKET MOUNTING
280
SHIELDING CENTRAL MUFFLER, L 00123120130331 M 00123120130331 A 13822220120928803
285
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
287
HEXAGON NUT W COLLAR BRACKET MOUNTING
288
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
290
HEXAGON NUT W COLLAR BRACKET MOUNTING
300
SHIELDING REAR LEFT, L 00123120130331 M 00123120130331 A 13822220120928803
310
SCREENING CENTRAL RIGHT FLOOR
320
HEXAGON NUT W COLLAR BRACKET MOUNTING
330
BOLT LOWER SUPPORT M6X19
340
LOCK NUT. SPRING NUT MOUNTING PARTS
360
SHIELDING REAR
370
HEXAGON NUT W COLLAR BRACKET MOUNTING
380
BRACKET
390
BOLT BRACKET TO SUBFLOOR M8X24
395
SCREENING PLATE BELOW FUEL TANK
400
TS BOLT ATTACHMENT SHIELD 5X12
410
HOOK ATTACHMENT SHIELD
