Поз.
Артикул
Описание
10
BRACKET CIRCULATION PUMP
20
CIRCULATION PUMP ADDITIONAL WATER PUMP, F 02214220020608 F 08950320040730805
30
VALVE CHANGE-OVER VALVE
40
COOLANT PIPE FROM VALVE TO ENGINE
50
LINE AT AIR CONDITIONER CASE
60
LINE TO VALVE
70
LINE FROM VALVE TO PUMP
80
COOLANT PIPE AT VALVE
90
FILLER NECK
100
CLAMP COOLING WATER PIPE MOUNTING
110
LINE HOLDER FROM HOSE TO PUMP
130
CLAMP
140
LINE HOLDER FROM HOSE TO PUMP
150
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
200
CLAMP POWER STEERING PUMP TO OIL TANK, FROM MODEL YEAR 2000CODE 800
210
CLAMP HOSE TO ENGINE 29/12MM
220
BRACKET
800
PIN BUSHING HOUSING OUTBOARD TEMPERATURE FEELER 2-PIN CODE A,B4,126373
805
CONTACT BUSHING WITH SINGLE-WIRE SEAL 0.5MM2,126373
900
PIN BUSHING HOUSING OUTBOARD TEMPERATURE FEELER 2-PIN CODE A,B4,126373
905
CONTACT BUSHING WITH SINGLE-WIRE SEAL 0.5MM2,126373
