Поз.
Артикул
Описание
5
IGNITION CONTROL BOX
5
IGNITION CONTROL BOX
8
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
8
NUT , Replaced By: N913023006001
8
NUT CONTROL UNIT TO BRACKET M 92884-0600D
11
SCREW HINGE LEVER TO ENGINE HOOD
14
CABLE HARNESS TRANSISTORIZED IGNITION, A 244936 F 146211 ONLY ON RETROFIT/CATALYST VEHICLES
17
NUT TACHOGRAPH TO BRACKET
17
NUT BALL PIVOT TO LEVER
20
LOCK WASHER T-FITTING TO BRACKET
20
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
23
IGNITION COIL , A 244936 F 146211 ONLY ON RETROFIT/CATALYST VEHICLES
23
IGNITION COIL , Replaced By: A0001586103
26
SUPPRESSOR HOUSING IGNITION COIL
29
SCREW HINGE LEVER TO ENGINE HOOD
32
WASHER
35
NUT BALL PIVOT TO LEVER
38
CLAMP CABLE HARNESS TO SIDE MEMBER
44
CABLE HARNESS TACHOMETER
44
CABLE HARNESS TACHOMETER
47
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
50
COVER , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
56
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
68
CABLE HARNESS FAN
71
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
74
COVERTO 008 545 08 28,008 545 09 28
74
CAP , Replaced By: A0125450428, +001A0125450528
77
ROUND PIN BUSHING4 MM2
80
PLUG HOUSING MAIN CABLE HARNESS
83
COVERTO 011 545 10 28
86
PLUG PIN
89
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
92
SHEET METAL SCREW MODULE TO HOUSING
92
SHEET METAL SCREW , Replaced By: N000000000453
95
SCREW , Replaced By: N007985004107
95
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
98
LOCK WASHER T-FITTING TO BRACKET
