Поз.
Артикул
Описание
5
ORNAMENTAL COVER RIGHT,AT REAR END PILLAR, TO BE PAINTED PRIOR TO INSTALLATION
5
ORNAMENTAL COVER LEFT,AT REAR PILLAR, TO BE PAINTED PRIOR TO INSTALLATION
8
CLIP VENTILATION SCREEN,RIGHT
8
CLIP VENTILATION SCREEN,LEFT
11
RIVET
14
TREENAIL
17
SHEET METAL SCREW
20
LEDGE , A 444048 F 494601
20
LEDGE (WATER DEFLECTOR),LEFT, A 444049 F 494602
20
LEDGE WHEN ORDERING, PLEASE STATE: NO. 7129
20
LEDGE (WATER DEFLECTOR),RIGHT, A 444049 F 494602
26
SEAL (WATER DEFLECTOR),LEFT, A 444049 F 494602
26
SEAL (WATER DEFLECTOR),RIGHT, A 444048 F 494601
26
SEAL (WATER DEFLECTOR),LEFT, A 444048 F 494601
26
SEAL (WATER DEFLECTOR),RIGHT
32
TREENAIL (WATER DEFLECTOR) ON FRONT PANEL PILLAR, A 444048 F 494601
35
SHEET METAL SCREW
38
SHEET METAL SCREW RELAY TO APPARATUS SUPPORT,K 182153K 239549
41
CLIP (WATER DEFLECTOR) ON FRONT PANEL PILLAR
44
RIVET
47
CLIP BLACK,WATER DEFLECTOR TO ROOF
47
CLIP WHITE,WATER DEFLECTOR TO ROOF
47
CLIP GREEN, WATER DEFLECTOR TO ROOF
50
CLIP BLACK,WATER DEFLECTOR TO ROOF,REAR
50
CLIP
50
CLIP WHITE,WATER DEFLECTOR TO ROOF,REAR
53
LEDGE RIGHT FRONT FENDER
53
LEDGE LEFT FRONT FENDER
56
LEDGE RIGHT FRONT DOOR, CENTRAL
56
LEDGE LEFT FRONT DOOR, CENTRAL
59
LEDGE RIGHT REAR DOOR, CENTRAL
59
LEDGE LEFT REAR DOOR, CENTRAL
62
CLIP LEFT AND RIGHT FRONT DOORS
65
LEDGE REAR FENDER,RIGHT FRONT
65
LEDGE REAR FENDER,LEFT FRONT
68
LEDGE REAR FENDER,RIGHT REAR
68
LEDGE REAR FENDER,LEFT REAR
71
CLIP PROTECTIVE STRIP TO FRONT FENDER
74
CLIP PROTECTIVE STRIP TO REAR FENDER,FRONT
77
SCREW , Replaced By: A2019902036
80
LEDGE FRONT FENDER,LEFT BOTTOM, A 070026 F 005092
80
LEDGE RIGHT BOTTOM, FRONT FENDER, A 070026 F 005092
83
LEDGE FRONT DOOR,RIGHT BOTTOM, A 070026 F 005092
83
LEDGE FRONT DOOR,LEFT BOTTOM, A 070026 F 005092
86
LEDGE REAR DOOR,RIGHT BOTTOM, A 070026 F 005092
86
LEDGE REAR DOOR,LEFT BOTTOM, A 070026 F 005092
89
LEDGE REAR FENDER,LEFT BOTTOM, A 070026 F 005092
89
LEDGE RIGHT BOTTOM, REAR FENDER, A 070026 F 005092
92
CLIP LEDGE TO FRONT FENDER
95
CLIP BLACK, LEDGE TO FRONT FENDER
98
SCREW , Replaced By: A2019902036
101
PANELLING RIGHT BOTTOM, REAR FENDER
101
PANELLING REAR FENDER,LEFT BOTTOM
104
FASTENER BUTTON
107
FASTENER BUTTON PANELLING TO REAR FENDER, 022 005892 024 011997
110
EXPANSION PLUG TO LOCK THE HOLES IN REAR FENDERS, A 174755 F 051107
113
COVERING JACK TAKE-UP DEVICE
999
FASTENER BUTTON , Replaced By: A0019882781
