Поз.
Артикул
Описание
5
CONTROL UNIT TEMPOMAT (CRUISE CONTROL)
5
CONTROL UNIT , Replaced By: A0145454032
5
CONTROL UNIT , Replaced By: A0165457732
5
CONTROL UNITTEMPOMAT,126. A 310459
8
CODING PART TEMPOMAT (CRUISE CONTROL) CONTROL UNIT,A 649304
11
SHEET METAL SCREW , Replaced By: N000000000459
11
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
14
LOCK PROTECTIVE GRILLE
14
LOCK , Replaced By: A0029941045
14
LOCK CONDENSER TO INTERIOR PLATE,LEFT OUTSIDE
17
CONTROL UNIT ACTUATOR
18
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
19
COVERTO 006 545 81 28
20
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
21
LEVER
26
NUT
29
LOCK
38
BRACKET ACTUATOR
44
SCREW 3/2-WAY VALVE TO BRACKET
50
GROMMET ACTUATOR TO BRACKET
56
SPACER ACTUATOR TO BRACKET, Replaced By: A0009923760
59
WASHER ACTUATOR TO BRACKET
65
STUD BOLT BRACKET TO ENGINE
68
NUT BATTERY MOUNTING
68
NUT CYLINDER TO BRACKET TO0002902112
137
CABLE HARNESS , Replaced By: A2015432426
137
CABLE HARNESS TEMPOMAT (CRUISE CONTROL), A 244936 F 146211
140
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
143
COVERTO 019 545 29 28
149
ROUND PIN BUSHING2.5 MM2
152
PIN BUSHING HOUSING 4-POLE
155
COVER
158
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
161
COVERTO 006 545 81 28
164
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
170
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
173
PLUG ADAPTERTO 014 545 04 28
176
PLUG ADAPTER. PLUG HEATING WATER VALVE, 4-POLE
179
PIN BUSHINGTO 000 821 19 26
182
PLUG HOUSING
185
PLUG PIN0.5-2.0 MM2
188
PIN BUSHING HOUSING. PLUG INCREASE IN SHIFT POINT, AUTOMATIC TRANSMISSION
194
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
194
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
197
COVERTO 011 545 10 28
200
ROUND PIN BUSHING4 MM2
203
BRACKET TEMPOMAT (CRUISE CONTROL) SWITCH PLUGCONNECTION, A 531256 F 664539 028 A 521683 028 F 655709 029 A 508035 029 F 646805 EXCEPT FOR A 506450,A 507076,A 507077,A 507078,A 507197,A 507198,A 507257,A 507634, F 640357, ALSO INSTALLED ON F 650026 FROM IDENT NO. 9/89 SEE KG 62
206
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
999
CABLE HARNESS FROM STOP LIGHT SWITCH TO CABLE CONNECTOR
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
LOCK WASHER T-FITTING TO BRACKET
