Поз.
Артикул
Описание
5
CABLE HARNESS LEFT HEADLAMP
8
CABLE HARNESS RIGHT HEADLAMP
14
PIN BUSHING HOUSING LEFT HEADLAMP CENTRAL ELECTRICAL SYSTEM, 14-POLE
17
PIN BUSHING HOUSING VALVE STRIP,8-POLE
20
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
23
ROUND PIN BUSHING LIGHT SWITCH
26
PIN BUSHING HOUSING HEADLAMP,WIPER MOTOR,BLOWER SWITCH
29
PLUG TRIPLE
29
PIN BUSHING HOUSING 4-POLE, BLOWER MOTOR
32
COVERTO 007 545 00 28
35
PIN BUSHING HOUSING FUSE BOX
38
PIN BUSHING HOUSING BIPOLAR
41
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
44
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
47
COVERTO 010 545 10 28
50
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
53
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
56
COVERTO 008 545 08 28
65
ROUND PIN BUSHING4 MM2
68
PLUG HOUSING BIPOLAR
71
COVERTO 008 545 08 28
74
PLUG PIN , 107.042 L.H.D. A 005252 107.042 R.H.D. A 007245 123. L.H.D. A 154544,F 019237 123. R.H.D. A 118487,F 020926
78
GROMMET BLINKER LAMP BRANCH-OFF
83
SCREW PUMP TO BRACKET
83
SCREW , Replaced By: N304017006016
86
SPRING WASHER LICENSE PLATE TO BRACKET
89
NUT , Replaced By: N913012006001
89
NUT , Replaced By: N913019006000
89
NUT CLAMP TO BRACKET
92
NUT , Replaced By: N910112006001
92
NUT , Replaced By: N913023006001
92
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
95
HORN400 HZ
95
HORN400 HZ,F 241917
98
HORN335 HZ
98
HORN
101
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
101
SCREW , Replaced By: N304017008016
104
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
116
SCREW ELECTRIC CABLE TO HORN
119
LOCK WASHER T-FITTING TO BRACKET
999
COVER PLATE
999
COVER DIAGNOSIS BOX
999
PLUG SOCKET DIAGNOSIS BOX
