Поз.
Артикул
Описание
8
EXHAUST PIPE FRONT
17
EXHAUST MUFFLER WITH PIPE CENTRAL
26
EXHAUST MUFFLER WITH PIPE REAR
32
CLAMP
32
CLAMP , Replaced By: A0004900741
35
SCREW , Replaced By: N304017008053
38
WASHER BRACKET TO CROSS MEMBER
41
NUT
44
SCREW , Replaced By: N304017008043
50
NUT POWER CYLINDER TO BRACKET
50
NUT , Replaced By: A0009903250
53
SEAL RING , Replaced By: A2024920381
53
SEAL RING
59
BRACKET FRONT EXHAUST PIPE TO TRANSMISSION, INAPPLICABLE TO VEHICLES EQUIPPED WITH CATALYST
68
CLAMPING BRACKET EXHAUST PIPE TO BRACKET
74
NUT POWER CYLINDER TO BRACKET
74
NUT , Replaced By: A0009903250
77
DISC SPRING EXHAUST PIPE TO BRACKET
80
WASHER HIGH PRESSURE HOSE TO BRACKET
83
SCREW , Replaced By: N304017008021
86
RUBBER RING BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
89
NUT BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
92
REPAIR KIT FRONT EXHAUST PIPE SUSPENSION
98
SUSPENSION RING MAIN MUFFLER SUSPENSION
101
CLAMPING PIECE MAIN MUFFLER SUSPENSION
104
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
104
SCREW , Replaced By: N304017008016
107
WASHER , Replaced By: N000125008443
110
DAMPING PAD EXHAUST PIPE SUSPENSION
999
CLAMP , Replaced By: A1244900041
999
EXHAUST MUFFLER WITH PIPE , Replaced By: A2014903315
999
EXHAUST MUFFLER WITH PIPE , Replaced By: A2014903415
