Поз.
Артикул
Описание
5
ACCELERATOR PEDAL , Replaced By: A2203000204
5
ACCELERATOR PEDAL
8
NUT ACCELERATOR PEDAL TO FIRE WALL
11
PIN ACCELERATOR PEDAL TO LEVER
14
LEVER ACCELERATOR PEDAL, A 450374 F 505054
14
LEVER ACCELERATOR PEDAL
14
LEVER ACCELERATOR PEDAL,F 505053
14
LEVER , Replaced By: A2023011620, +001A1293010218, +001N912007006001
17
LEVER ,B 838715,J 003393 TO BE ADAPTED DURING ASSEMBLY
20
INSULATING HOSE5 X 0.6 MM, ORDER BY THE METER
23
BEARING ACCELERATOR PEDAL BEARING,B 838715,J 003393
24
BEARING ACCELERATOR PEDAL BEARING,A 346276
26
CLIP CABLE TO BRACKET,5 318121
29
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
32
GASKET BEARING TO FIRE WALL
35
NUT RETAINER LICENSE PLATE TO BRACKET
38
SPRING ACCELERATOR PEDAL
47
SWITCH ONLY USED W/ACCELERATION SKID CONTROL (ASR)
50
PLUG PIN0.5-2.0 MM2
53
PLUG PLUG CONNECTION,A 159402 AUSTRALIA UP TO END OF MODELYEAR 93
56
SCREW ONLY USED W/ACCELERATION SKID CONTROL (ASR)
56
SCREW , Replaced By: A0049906112
59
WIRE CABLE , Replaced By: A2083000030
59
WIRE CABLE , Replaced By: A2023001330
59
WIRE CABLE , Replaced By: A2023000630
59
WIRE CABLE ,F 547166F 711024
59
WIRE CABLE , A 470873 F 547165
59
WIRE CABLE , UP TO END OF MODEL YEAR 1996
65
GUIDE
68
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
73
EXPANSION PLUG
77
BRACKET , A 470874 F 547166 A 519673 F 619720 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE FROM A 519674, F 619721 WITH CODE 807
77
BRACKET ,F 547165
77
BRACKET , Replaced By: A2103011540
80
SENDER UNIT , Replaced By: A0125423317
83
LEVER (REVERSING LEVER),F 547165
84
LEVER , Replaced By: A2103001128, +001A1689930320
84
LEVER (REVERSING LEVER), F 619721 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE TO F 619720 WITH CODE 808
87
ROLLER , NOT USED
88
LOCK PLATE , 656999
89
LOCK PLATE RELEASE LEVER TO SHAFT
92
SCREW PUMP TO BRACKET
92
SCREW , Replaced By: N304017006016
95
SPRING , NOT USED
99
SPRING AT REVERSING LEVER,A 346276
100
CLAMPING PIECE AT REVERSING LEVER,A 346276
101
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
