Поз.
Артикул
Описание
10
PANELING
10
TRIM PANEL TUNNEL
10
TRIM PANEL TUNNEL
10
TRIM PANEL TUNNEL
10
TRIM PANEL TUNNEL
10
TRIM PANEL TUNNEL
30
HOUSING WITH ASHTRAY
30
HOUSING WITH TRAY
32
STORAGE SPACE
35
STORAGE SPACE WITH ASHTRAY
35
STORAGE SPACE
40
SOCKET-OUTLET MULTIFUNCTION BOX
40
PLUG SOCKET IN THE HOUSING
50
CIGARETTE LIGHTER
50
CIGARETTE LIGHTER
60
TRUSS
70
ASHTRAY INSERT
72
ASHTRAY POT
75
INSERT
75
INSERT
80
HEX. ROUND SCREWS. SCREW BRACKET TO SUPPORT M5 X 20
85
HEXALOBULAR BOLT. SCREW BRACKET TO SUPPORT M5 X 12
110
COVER ASHTRAY HOUSING
110
COVER ASHTRAY HOUSING
110
COVER ASHTRAY HOUSING
110
COVER ASHTRAY HOUSING
110
COVER HOUSING
110
COVER HOUSING
110
CLOSING COVER
120
COVER FOR SHIFTING GATE
120
COVER FOR SHIFTING GATE
120
COVER FOR SHIFTING GATE
120
COVER FOR SHIFTING GATE
120
COVER FOR SHIFTING GATE
120
COVER FOR SHIFTING GATE
120
COVER GEARSHIFT MECHANISM
120
COVER FOR SHIFTING GATE
120
COVER GEARSHIFT MECHANISM
120
COVER GEARSHIFT MECHANISM
120
COVER FOR SHIFTING GATE
140
SUNBLIND
140
SUNBLIND
140
SUNBLIND
150
COVER, STOWAGE TRAY
160
DASHPOT IN HOUSING CENTER CONSOLE
170
TRUSS CUP HOLDER
200
STORAGE COMPARTMENT FLAP
200
COVER ARMREST, Replaced By: A2046803239
200
STORAGE COMPARTMENT FLAP ARMREST
250
NOZZLE
250
NOZZLE
250
NOZZLE
250
NOZZLE
260
LINING IN STOWAGE COMPARTMENT
300
COVER
310
ASHTRAY
350
HEX. ROUND SCREWS. SCREW BRACKET TO SUPPORT M5 X 20
360
NUT-AND-WASHER ASSEMBLY BRACKET TO FLOOR M6
370
BOLT LOWER SUPPORT M6X19
400
IMPELLER BLOWER
410
PAN HEAD SCREW. SCREW GROUND CONNECTION
450
CONSOLE REAR ENTERTAINMENT
470
TAKE-UP DEVICE REAR ENTERTAINMENT, 9051QFT204A6005 BLACK
480
TAPPING SCREW HANDLE TO PANELLING
490
SOCKET-OUTLET CENTRAL CONSOLE REAR 12V
500
REINFORCEMENT REAR ENTERTAINMENT, 9051QFT204A6005 BLACK
550
MOUNTING PLATE IN CENTRAL CONSOLE
552
OPTICAL FIBER
555
BOLT. SCREW (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR,AXLE,LEFT AND RIGHT,V 207570
900
PIN BUSHING HOUSING STEERING COLUMN ELECTRICALLY ADJUSTABLE 4-POLIG, A 843748 X 019421
902
PIN BUSHING HOUSING WARNING DEVICE
904
HOUSING SEAT RECOGNITION FUNCTION SWITCH 2-PIN MQS,S100
906
PLUG HOUSING IGNITION LOCK 5-PIN SLK2.8,N73
908
PLUG CIGAR LIGHTER (SOCKET) 3-PIN WDF2,R3/1
