Поз.
Артикул
Описание
10
DASHPOT
10
DASHPOT
10
DASHPOT
10
DASHPOT
30
PUMP FOR WINDSHIELD WASHER
40
GROMMET FROM PUMP INTO RESERVOIR 11 MM, IMPORTANT! WHEN ORDERING THE GROMMET, MEASURE HOLE DIAMETER AT WINDSHIELD WASHER SYSTEM RESERVOIR AND SEEK SUITABLE GROMMET.
50
COVER
60
HEAT EXCHANGER
65
SPACER BUSH FOR HEAT EXCHANGER
70
CAP FOR HEAT EXCHANGER WASHER FLUID HEATER, Replaced By: A2518350139
70
CAP FOR HEAT EXCHANGER FOR HEAT EXCHANGER
75
SEAL
80
GROMMET
150
PUMP HEADLAMP CLEANING SYSTEM
160
GROMMET FROM PUMP INTO RESERVOIR
200
SEAL BETWEEN RESERVOIR AND BODY
220
SCREW LEVER TO ENGINE CONTROL SHAFT
230
LOCK NUT. SPRING NUT MOUNTING PARTS
240
ROTARY CATCH FOR TANK TO BODY
242
CLIP-TYPE FASTENER FOR TANK TO BODY
250
HOSE ASSY. WITH NOZZLES
250
HOSE ASSY. WITH NOZZLES
260
CLIP FOR HOSE TO COVER
270
MOUNTING CLAMP HOUSING, A 42814020020812 E 02000020070101
280
CLAMP20 MM
900
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
904
PIN BUSHING HOUSING INDICATOR SWITCH,POWER TAKE-OFF S23.2/.3, 2 PIN
908
PIN BUSHING HOUSING. PLUG SOCKET SOLENOID VALVE,POWER TAKE-OFF Y46.2/.3 2PIN
