Поз.
Артикул
Описание
10
CROSS MEMBER UNDERNEATH REAR SEAT, A 11853120080107 L 00481320071231 V 00024120071231 F 11609720080106 L 10000020090901
30
BOTTOM UNDERNEATH REAR SEAT
40
COVER MAINTENANCE OPENING FOR FUEL PUMP
50
SEALING CORD , ORDER BY THE METER
60
SCREW
100
CONSOLE UNDERNEATH REAR SEAT
100
CONSOLE UNDERNEATH REAR SEAT
110
SIDE MEMBER REAR LEFT
115
PIPE LEFT
120
CONSOLE LEFT
125
WHEELHOUSE REAR LEFT
130
FIXTURE REAR AXLE MOUNTING,FRONT
135
SIDE MEMBER REAR SEAT BENCH,LEFT
135
LONGITUDINAL MEMBER REAR SEAT BENCH,LEFT
140
SIDE MEMBER REAR RIGHT
140
SIDE MEMBER REAR RIGHT, Replaced By: A2046102610
145
PIPE RIGHT
150
CONSOLE LEFT
155
WHEELHOUSE REAR RIGHT
160
FIXTURE REAR AXLE MOUNTING,FRONT
165
SIDE MEMBER REAR SEAT BENCH,RIGHT
165
LONGITUDINAL MEMBER REAR SEAT BENCH,RIGHT
170
CONSOLE REAR AXLE MOUNTING,FRONT
180
REINFORCEMENT RIGHT REAR WHEEL ARCH
190
BRACKET LEFT BRAKE HOSE
200
BRACKET RIGHT BRAKE HOSE
205
STAY LEFT
210
STAY RIGHT
220
CROSS MEMBER REAR AXLE,FRONT
230
CROSS MEMBER LOADING FLOOR
230
CROSS MEMBER LOADING FLOOR
240
REINFORCEMENT BACKREST LOCKING MECHANISM,LEFT
260
REINFORCEMENT BACKREST LOCKING MECHANISM,RIGHT
270
CONSOLE LEFT SEAT BELT RETRACTOR
275
BOLT LOWER SUPPORT M6X19
280
CONSOLE RIGHT SEAT BELT RETRACTOR
285
BOLT LOWER SUPPORT M6X19
300
CROSS MEMBER REAR AXLE
310
REINFORCEMENT LEFT
320
CONSOLE LEFT REAR AXLE SPACER
330
REINFORCEMENT RIGHT
340
CONSOLE RIGHT REAR AXLE SPACER
360
CROSS MEMBER REAR AXLE,TOP
380
CONSOLE LOADING FLOOR,LEFT
400
CONSOLE LOADING FLOOR,RIGHT
420
BOLT MOUNTING, SUPPORT TO FRAME
440
NUT , Replaced By: N913023006001
890
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
895
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
