Поз.
Артикул
Описание
10
TRUNK LID
10
TRUNK LID
20
HINGE LEVER RIGHT
20
HINGE LEVER LEFT
50
SCREW INTAKE SHELL TO BRACKET,A 213305
60
BOLT LOWER SUPPORT M6X19
70
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
80
RETAINER WEDGE TRUNK LID, RIGHT
100
EXTENSION SPRING LEFT AND RIGHT
110
INSULATION TENSION SPRING
130
SEALING FRAME
150
TRIM PANEL TRUNK LID , 9F08QFT205A0665 SINGLE TONE BLACK
150
TRIM PANEL TRUNK LID , 9F08QFT205A0665 SINGLE TONE BLACK
150
TRIM PANEL TRUNK LID , 9F08QFT205A0665 SINGLE TONE BLACK
150
TRIM PANEL TRUNK LID , 9F08QFT205A0665 SINGLE TONE BLACK
155
FRAME SEGMENT INTERIOR LAMP
170
PLUG-IN MOUNTING LEFT PANELLING TO BODY, F 50004620100331
190
HANDLE RECESS IN PANELLING, 9051QFT205A0680 BLACK
200
RIVET BUSHING AND LEVER TO CAB
220
INTERIOR LAMP IN REAR-END DOOR
225
LAMP HOLDER INTERIOR LAMP 12V-5W, J 42086420061222
227
BULBTO A 6955407048/7148,3825400311/0411
240
CABLE DUCT REAR LID HINGE,RIGHT, 9051QFT205A0670 BLACK
240
CABLE DUCT REAR LID HINGE,LEFT, 9051QFT205A0670 BLACK
260
PLUG-IN MOUNTING LEFT PANELLING TO BODY, F 50004620100331
280
SWITCH LUGGAGE COMPARTMENT INTERIOR CONTROL, A 23717420010831 F 16659520010831
290
RETAINER WEDGE BOTTOM LEFT & RIGHT
300
SWITCH REMOTE TRUNK LOCKING WITH KEYLESS GO
300
SWITCH REMOTE TRUNK LOCKING
350
RETAINER WEDGE TOP LEFT AND RIGHT
360
STOP PLUG BATTERY CASE 6.5 MM
400
DRIVE UNIT TRUNK LID
420
STANCHION
440
RUBBER BUMPER
460
CONSOLE
470
HEXALOBULAR BOLT. SCREW STEP TO ENTRANCE
480
NUT , Replaced By: N913023006001
500
CONSOLE HINGE LEVER
520
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
