Поз.
Артикул
Описание
5
CABLE HARNESS ENGINE CABLE HARNESS,BODY MOUNTED, A 698507 X 012425 EXCEPT CODE 809 ALSO INSTALLED IN VEHICLE FROM A 698508, X 012426 WITH CODE 808
5
CABLE HARNESS ENGINE CABLE HARNESS,BODY MOUNTED, A 698508 X 012426 EXCEPT CODE 808 ALSO INSTALLED IN VEHICLE TO A 698507, X 012425 WITH CODE 809
14
PIN BUSHING HOUSING OUTBOARD TEMPERATURE FEELER 2-PIN CODE A,B4,126373
17
CONTACT BUSHING WITH SINGLE-WIRE SEAL 0.5MM2,126373
29
PIN BUSHING HOUSING FOLDING TOP ACTUATION VALVE
38
ROUND PIN BUSHING2.5 MM2
44
PIN BUSHING HOUSING BIPOLAR
50
PIN BUSHING HOUSING BIPOLAR
59
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
68
PIN BUSHING HOUSING HEATING WATER VALVE
71
ROUND PIN BUSHING4 MM2
95
PIN BUSHING HOUSING BELT FEEDER
98
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
110
CONTACT SPRING , Replaced By: A0115457626
110
CONTACT SPRINGTO 657 540 50 10
114
PIN BUSHING HOUSING WIPER MOTOR
116
CONTACT SPRING1-2.5 MM2
116
CONTACT SPRING0.5-1.0 MM2, Replaced By: A0005406905
116
CONTACT SPRING0.5-1.5 MM2
116
CONTACT SPRING2,5 MM2
152
PLUG PIN0,5-1,0 MM
155
LAMP HOLDER. SOCKET ADDITIONAL BLINKER LAMP
164
BRACKET DIAGNOSIS PLUG SOCKET,V 202043
167
SCREW AUTOMATIC HEATING OPERATING UNIT TO LEDGE IN HOUSING,TOP
179
NUT
179
NUT , Replaced By: N304032008006
179
NUT TACHOGRAPH TO BRACKET
182
SPRING WASHER , Replaced By: N000137008212
182
SPRING WASHER ALTERNATOR CONNECTION D+
185
CAP SCREW HEAD COVERING
185
BOOT , Replaced By: N913018013201
185
PROTECTION CAP , Replaced By: A0008310929
191
GROMMET AT PARTITION PANEL
224
CLIP CABLE HARNESS TO ROOF RAIL
