Поз.
Артикул
Описание
4
FILTER MULTI-STAGE FUEL FILTER
4
FILTER MULTI-STAGE FUEL FILTER
4
FUEL FILTER , Replaced By: A4220900152
4
FILTER , Replaced By: A4420900352
12
COVER , Replaced By: A4220900012
12
COVER , Replaced By: A4220920108
12
FILTER HEAD FUEL FILTER
12
FILTER HEADTO 442 090 03 52
20
FILTER ELEMENT , Replaced By: A0000901451
20
TS AIR FILTER ELEMENT WITH SEAL RING
24
SEAL RING FUEL FILTER COVER
36
HOUSING
36
HOUSING
36
HOUSINGTO 001 477 14 01
44
SCREW REAR AXLE REGULATING SOLENOID VALVE
44
SCREW PRESSURE REGULATOR TO BRACKET
56
SEAL RING SCREW PLUG
68
SCREW BREATHER TO 422 090 02 52
68
SCREW , Replaced By: A4420740071
121
HOLLOW SCREW FUEL LINE TO FEED PUMP
123
SEAL RING INJECTION PUMP
125
SCREW PLUGTO 000 553 03 05,000 553 18 05,
125
SCREW PLUG , Replaced By: N000908014009
128
VALVE , Replaced By: A0000920610
128
VALVE FUEL FILTER
134
SEAL RINGTO 000 553 03 05,000 553 18 05,
134
SEAL RING INJECTION PUMP
146
BRACKET FUEL FILTER
146
SUPPORT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4210920740
152
THREADED INSERT
155
STUD FUEL FILTER
234
WASHER RADIATOR TO RUBBER MOUNTING
236
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
236
SCREW BRACKET TO FRAME SIDE MEMBER
236
SCREW , Replaced By: N304017008042
236
SCREW AT SHIFT LEVER M 8 X 45,P 234011
238
NUT BATTERY CABLE
254
BRACKET FUEL FILTER
258
SCREW LEFT AND RIGHT CONSOLES TO CAB
258
SCREW CABLE HARNESS MOUNTING
258
HEXAGON HEAD BOLT BRACKET TO CROSS MEMBER
260
SCREW BRACKET TO SIDE MEMBER,K 168169
260
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET M 8X95
260
SCREW BRACKET TO ALTERNATOR
274
SCREW BRACKET TO SIDE MEMBER M10X38
278
WASHER EXHAUST MUFFLER TO STRAP
278
WASHER , Replaced By: N000125008443
280
WASHER RADIATOR TO RUBBER MOUNTING
282
SPRING WASHER CAB FLOOR
290
BRACKET FUEL FILTER
292
BRACKET FUEL FILTER
294
BRACKET , Replaced By: A4230900341
294
BRACKET DOUBLE FUEL FILTER,MULTI-STAGE FUEL FILTER
296
BRACKET
305
SPACER TUBE FUEL FILTER TO SUPPORT TO 421 092 08 40
306
HEXAGON HEAD BOLT BRACKET TO CROSS MEMBER
306
SCREW LEFT AND RIGHT CONSOLES TO CAB
306
SCREW RUBBER MOUNTING TO ENGINE M 12X35
306
HEXAGON HEAD BOLT , Replaced By: A0029902704
306
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
306
SCREW CLAMP TO 693 460 70 05,71 05
306
SCREW STRUT TO SIDE MEMBER M 12X55
306
SCREW , Replaced By: N304017012013
306
SCREW , Replaced By: N000960012384
306
SCREW ,5 903514, Replaced By: N000960012353
306
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
306
SCREW AIR-DEHYDRATOR BRACKET
312
SCREW , Replaced By: N308676012012
312
HEXAGON HEAD BOLT , Replaced By: A0029902704
312
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
318
SPRING WASHER CAB FLOOR
324
WASHER
326
MOUNTING LEDGE MULTI-STAGE FUEL FILTER TO 403 092 08 40
334
SPACER TUBE MULTI-STAGE FUEL FILTER
334
SPACER TUBE FUEL FILTER TO CHARGING AIR PIPE
336
BRACKET OIL FILTER
336
BRACKET
398
BRACKET , Replaced By: A4210920640
398
BRACKET , Replaced By: A4210920840
398
BRACKET (TRANSVERSE CHARGING AIR PIPE)
402
WASHER RADIATOR STRUT TO SUPPORT AND TO CAB
404
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
408
SCREW. HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRAKE ANCHOR M10X16
413
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
413
SCREW FITTING , Replaced By: A4039971172
418
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420785641, +001A4420901641
418
BRACKET BREATHER PIPE
418
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A4220780041
444
SPACER TUBE BRACKET TO TRANSMISSION
446
SCREW BEARING BRACKET TO FRAME
446
SCREW SUPPORTING ARM TO ENGINE
446
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
446
SCREW LEFT AND RIGHT CONSOLES TO CAB
446
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
446
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE M 12X1.5X55
446
SCREW , Replaced By: N000961012051
480
SCREW , Replaced By: N308676012012
480
SCREW , Replaced By: N308676012018
480
SCREW , Replaced By: N000961012051
480
SCREW STRUT TO FRAME M 12X62
480
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
480
SCREW LEFT AND RIGHT CONSOLES TO CAB
480
HEXAGON HEAD BOLT , Replaced By: A0029902704
480
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
480
SCREW BEARING BRACKET TO FRAME
480
HEXAGON HEAD BOLT. SCREW REINFORCEMENT TO SIDE MEMBER M 12X55
484
SPRING WASHER CAB FLOOR
579
ADAPTER FITTING EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
579
INTERMEDIATE PIECE EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
580
SCREW FITTING , Replaced By: A4039971172
580
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
581
SEAL RING FUEL LINE TO FEED PUMP
588
BRANCH-OFF FITTING BRACKET TO TIMING CASE COVER
598
CONNECTOR FUEL FEED AND FUEL RETURN TO FUEL DISTRIBUTOR
600
SCREW , Replaced By: N304017008043
600
SCREW VALVE TO BRACKET M 8X55
600
SCREW STRAP TO EXHAUST MUFFLER
601
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
602
NUT , Replaced By: N304032008006
602
NUT
783
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 716010, Replaced By: A4420784741
783
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A4220780041
783
BRACKET FUEL RETURN,517679
786
CLAMP
792
BASE , Replaced By: A3142030084
794
SCREW , WITH DIESEL ENGINE
794
SCREW CAB FLOOR COVERING M 6X25
794
SCREW COVER PLATE TO COVER PLATE M 6 X 12
794
SCREW , Replaced By: N304017006018
794
SCREW , Replaced By: N304017006016
794
SCREW PUMP TO BRACKET
796
LOCK WASHER WIRE CABLE TO LEVER
796
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
798
NUT SPRING-LOADED PUSH ROD
802
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
802
LOOM TIE LINE MOUNTING 280 MM
999
WASHER , Replaced By: N000125008443
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
NUT , Replaced By: N304032008006
999
WASHER , Replaced By: N007349008007
999
WASHER
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW SUPPORT TO FENDER
999
COMBINATION BOLT LEFT & RIGHT CHARGE AIR PIPES TO CYLINDER HEAD M 8X93
999
NUT. UNION NUT RETURN
999
FITTING WATER SEPARATOR
999
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
SEPARATOR (WATER SEPARATOR)
999
NUT
999
BANJO UNION FUEL LINES AND BREATHING
999
STUD
999
CLAMPING PIECE FUEL FILTER TO BRACKET,012710
999
FITTING RETURN
999
LOOM TIE LINE MOUNTING
999
FITTING FUEL LINE TO HAND PUMP
999
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
INTERMEDIATE PIECE AT INJECTION PUMP
999
LINE FROM FUEL DISTRIBUTOR TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
999
LINE FROM FUEL FILTER TO INJECTION PUMP
999
LINE FROM FUEL FEED PUMP TO DISTRIBUTOR,062710
999
BRACKET , Replaced By: A4220901241
999
FILTER , Replaced By: A4420900452
999
PLATE LINE MOUNTING,920657
999
LINE
999
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION, NOT USED
999
LINE FROM FEED PUMP TO FILTER, NOT USED
999
LINE , Replaced By: A4470700432
999
LINE FROM FUEL FILTER TO INJECTION PUMP, NOT USED
999
LINE , Replaced By: A4470700332
